Summary of Contents for ADLINK Technology ReadyBoard 910

  • Page 1: Reference Manual

    ReadyBoard ™ Single Board Computer Reference Manual P/N 50-1Z115-1000...
  • Page 2 Notice Page DISCLAIMER ADLINK Technology, Incorporated makes no representations or warranties with respect to the contents of this manual or of the associated ADLINK products, and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. ADLINK shall under no circumstances be liable for incidental or consequential damages or related expenses resulting from the use of this product, even if it has been notified of the possibility of such damages.

  • Page 3: Table Of Contents

    External Beeper/Buzzer Interface ....................31 Clear CMOS Switch .......................31 System Reset Switch ......................31 Temperature Monitoring ......................32 User GPIO Signals ........................32 Oops! Jumper (BIOS Recovery) ....................32 Serial Console ..........................33 Serial Console Setup......................33 System Management Bus (SMBus)..................33 Watchdog Timer ........................34 ReadyBoard 910 Reference Manual...
  • Page 4 Index ..............................55 List of Figures Figure 2-1. Typical ReadyBoard and PC/104 Module Stack ............. 3 Figure 2-2. PCI-104 Modules Stacked on a ReadyBoard 910........... 4 Figure 2-3. Functional Block Diagram ..................8 Figure 2-4. Component Locations ..................10 Figure 2-5.
  • Page 5 CPU Fan Interface Pin Signal Descriptions (FN1) ..........35 Table 3-21. System Fan Interface Pin Signal Descriptions (FN2) ..........36 Table 3-22. Wake Up Activities and Conditions ................38 Table 4-1. BIOS Setup Menus ....................41 Table A-1. Technical Support Contact Information..............53 ReadyBoard 910 Reference Manual...
  • Page 6 Contents Reference Manual ReadyBoard 910...

  • Page 7: Chapter 1 About This Manual

    About This Manual Purpose of this Manual This manual is for designers of systems based on the ReadyBoard 910 Single Board Computer (SBC). The information in this manual helps designers create embedded systems based on specific design requirements. Information provided in this reference manual includes: •...
  • Page 8 Standard Microsystems Corp and the SCH3114I-NU chip, used for the Super I/O controller. Web site: http://www.smsc.com/main/catalog/sch311x.html NOTE If you are unable to locate the datasheets using the links provided, search the internet to find the manufacturer’s web site and locate the documents you need. Reference Manual ReadyBoard 910...

  • Page 9: Chapter 2 Product Overview

    Chapter 2 Product Overview This overview presents general information about the EPIC form factor and the ReadyBoard 910 Single Board Computer (SBC). After reading this chapter you should understand: • EPIC architecture • Product Description • ReadyBoard 910 features •...

  • Page 10: Product Description

    Ethernet interfaces through PCIe x1 Ports 3 and 4, one PCI-104 interface through PCIe x1 Port 2, and one PCIe Mini Card interface through PCIe x1 Port 6. The ReadyBoard 910 can be expanded through the PCI-104 expansion bus to accept PCI-104 cards that offer compact, self-stacking, modular expandability for additional system functions. The PCI-104 bus only implements the signal set for the PCI bus and is available on the 120-pin (4 rows of 30 pins) expansion bus connector.

  • Page 11: Board Features

    Provide two buffered serial ports with full handshaking ♦ Provide one 10-pin header for one serial port ♦ Provide one 9-pin standard DB9 connector for one serial port ♦ Provide 16550-equivalent controllers, each with a built-in 16-byte FIFO buffer ♦ ReadyBoard 910 Reference Manual...
  • Page 12 Support LVDS resolutions up to 1920x1080 at 60Hz ♦ • Miscellaneous Provides real-time clock (RTC) with replaceable battery ♦ Supports battery-free boot ♦ Provides external battery connection for RTC operation ♦ Provides user GPIO interface header ♦ Provides thermal and voltage monitoring ♦ Reference Manual ReadyBoard 910...
  • Page 13 Provides headers for optional CPU and System fans (+12 volt power supply required) ♦ Supports a customizable Logo (Splash) Screen (contact Sales Representative) ♦ Supports Serial Console ♦ Provides Watchdog Timer ♦ Provides EXT header for optional CAN and Telecom modules ♦ ReadyBoard 910 Reference Manual...

  • Page 14: Block Diagram

    Chapter 2 Product Overview Block Diagram Figure 2-3 illustrates the functional components of the ReadyBoard 910. 1067/1333MHz, 1.5V, 16GB Max. Intel DDR3 Core i5 2510E (Dual-Core) 2.5GHz or Channel - A SODIMM Core i7 2710QE (Quad-Core) 2.1GHz Sockets (2) Channel - B...

  • Page 15: Major Components (Ics)

    Product Overview Major Components (ICs) Table 2-1 lists the major Integrated Circuits (ICs) on the ReadyBoard 910, including a brief description of each IC. Figure 2-4 shows the locations of the major ICs. Table 2-1. Major Component Descriptions and Functions Chip Type Mfg.

  • Page 16: Figure 2-4. Component Locations

    U26 - Audio Codec U30 - CPU U33 - Gb Ethernet Controller - GLAN1 U34 - Gb Ethernet Controller - GLAN2 U38 - Ethernet EEPROM - GLAN1 U46 - RS-232 Transceiver - COM0-1 Figure 2-4. Component Locations Reference Manual ReadyBoard 910...

  • Page 17: Header, Connector, And Socket Definitions

    CN21 – PCIe Mini Card Bottom 52-pin, 0.012" (0.30mm) standard socket for PCI Express Mini (on bottom side) Card signals CN22 – DDR3 Bottom 204-pin, standard socket for non-ECC, unbuffered DDR3 SODIMM2 (on bottom SODIMM side) ReadyBoard 910 Reference Manual...

  • Page 18: Figure 2-5. Header And Connector Pin Sequence

    6 is directly across from pin 1, is noted in this way: 10-pin, 2 rows, consecutive (1, 6). The second number in the parenthesis is always directly across from pin-1. See Figure 2-5. 10-pin, two rows, Odd/Even, (1, 2) Figure 2-5. Header and Connector Pin Sequence Reference Manual ReadyBoard 910...

  • Page 19: Figure 2-6. Header, Connector, And Socket Locations

    (Power Select S3/S5 Power On) CN12 CN14 CN11 CN10 CN13 Figure 2-6. Header, Connector, and Socket Locations NOTE Pin 1 is shown as a black pin (square or round) on all connectors and headers in all illustrations. ReadyBoard 910 Reference Manual...

  • Page 20: Jumper Header Definitions

    JP5 - See I/O Header Table (Beeper/Buzzer) JP6 - See I/O Header Table (Power Button) JP7 - See I/O Header Table (SMBus - DATA) JP8 - See I/O Header Table (SMBus - CLOCK) Figure 2-7. Jumper Header Locations (Top Side) Reference Manual ReadyBoard 910...

  • Page 21: Specifications

    Chapter 2 Product Overview Specifications Power Specifications Table 2-4 lists the power requirements for the ReadyBoard 910. Table 2-4. Power Supply Requirements Parameter 2.5GHz Intel Core i5 2.1GHz Intel Core i7 Characteristics Characteristics Input Type Regulated DC voltages Regulated DC voltages In-rush Current (Peak) 10.56A (126.72W)

  • Page 22: Thermal/Cooling Requirements

    Product Overview Thermal/Cooling Requirements The ReadyBoard 910 is designed to operate at its maximum CPU speeds of 2.1GHz, and 2.5GHz and requires a thermal solution to cool the CPU, PCH, and voltage regulators. ADLINK offers two optional cooling solutions. (See Table 2-6 for descriptions of cooling options.)

  • Page 23: Mechanical Specifications

    Chapter 2 Product Overview Mechanical Specifications Figures 2-8 provide the I/O panel and mounting hole dimensions of the ReadyBoard 910. Power/SATA Gigabit USB 1 & 2 Keyboard/ Activity Ethernet 1 Mouse (USB 1 Lower) Gigabit Ethernet 2 Reset Switch 165.1 4.572...

  • Page 24: Figure 2-9. Mechanical Overview (Top Side)

    Chapter 2 Product Overview 0.20 (5.08mm) 0.00 0.00 0.02 (0.55mm) 2.03 (51.55mm) 2.50 (63.40mm) 2.52 (64.03mm) 4.76 (120.82mm) 5.52 (140.24mm) 5.55 (140.87mm) 5.70 (145.02mm) 6.10 (154.84mm) 6.30 (159.92mm) Figure 2-9. Mechanical Overview (Top Side) Reference Manual ReadyBoard 910...

  • Page 25: Chapter 3 Hardware

    Chapter 3 Hardware Overview This chapter discusses custom features of the ReadyBoard 910 in the following order: • Interrupt Channel Assignments • Memory Map • I/O Address Map • Serial Interfaces • USB Interfaces USB 3.0 Support (2 ports) ♦...

  • Page 26: Cpu

    DirectX Video Acceleration (DXAV), Advanced Scheduler 2.0, 1.0, and XPDM. Memory The ReadyBoard 910 features dual-stacked SODIMM sockets for up to 16 GB of DDR3 memory. The CPU provides an Integrated Memory Controller (IMC) with DDR3 protocols and two independent, 64-bit wide channels each supporting two unbuffered non-ECC SODIMMs, employing up to two device ranks per channel.

  • Page 27: Interrupt Channel Assignments

    Legend: D = Default, O = Optional, X = Fixed NOTE The IRQs for the Ethernet, Video, and USB are automatically assigned by the BIOS Plug and Play logic. Local IRQs assigned during initialization can not be used by external devices. ReadyBoard 910 Reference Manual...

  • Page 28: Memory Map

    0070-007F CMOS RAM, NMI Mask Reg, RT Clock 0080 System reserved 0081-0083 DMA Page Registers 0084-0086 System reserved 0087 DMA Page Register 0088 System reserved 0089-008B DMA Page Registers 008C-008E System reserved 008F DMA Page Register Reference Manual ReadyBoard 910...
  • Page 29 Slave DMA Controller #2 00E0-00EF System reserved 00F0-00FF Math Coprocessor 01F0-01F7 SATA Controller 02F8-02FF Serial Port 2 (COM2) 03B0-03BB Video (monochrome) 03C0-03DF Video (VGA) 03F8-03FF Serial Port 1 (COM1) 04D0-04D1 Edge/Level Trigger PIC 0CF9 Reset Control Register ReadyBoard 910 Reference Manual...

  • Page 30: Serial Interfaces

    The RS-422 mode uses a four-wire interface and does not need any pins tied together, but you must select RS-485 mode in BIOS Setup. Serial Port 2 Standard DB9 Serial Port 1 (CN8, COM1) (CN17, COM0) Connector (Male) Front View Figure 3-1. RS-485 Serial Port Implementation Reference Manual ReadyBoard 910...

  • Page 31: Table 3-4. Serial Port 2 (Cn8) Interface Pin Signals

    Ground Key/NC Key Pin/Not connected Note: The shaded table cells denote power or ground. Signals appear in the second column as RS-232 followed by RS-485/RS-422. The * symbol indicates the signal is Active Low. ReadyBoard 910 Reference Manual...

  • Page 32: Usb Interfaces

    Hardware USB Interfaces The ReadyBoard 910 offers state-of-the-art USB 3.0 support through the PCH using PCIe x1 Port 1 and a USB 3.0 xHCI host controller module. Features of the USB 3.0 interface include up to two downstream ports (each independently enabled or disabled), SuperSpeed, High-Speed, and Full-Speed signals, and support for input frequencies between 20MHz and 50MHz.

  • Page 33: Video Interfaces

    Provide Hot Plug detect for guaranteed “input LOW” when not connected • Support lossless (digital) transmission of video signals • Support display hardware independence • Provide plug and play capabilities (EDID and DDC2B) • Provide digital and analog support in a single connector ReadyBoard 910 Reference Manual...

  • Page 34: Dvi

    Serial Clock - DDC (I2C) TMDSDVI_CLOCK_N TMDS Clock Negative DVI_SDA_CN Serial Data - DDC (I2C) Digital Ground DVI_HPD_CN Hot Plug Detect - DDC (I2C) Digital Ground Not Connected Not Connected Note: The shaded table cells denote power or ground. Reference Manual ReadyBoard 910...

  • Page 35: Lvds Interface

    Data Negative Output LB_DATA1_P Data Positive Output Ground LB_DATA1_N Data Negative Output Channel 2 LB_DATA2_P Data Positive Output Ground LB_DATA2_N Data Negative Output LB_DATA3_P Data Positive Output Ground LB_DATA3_N Data Negative Output LCD_BLON Backlight Enable Ground ReadyBoard 910 Reference Manual...

  • Page 36: Ext Interface

    PCH_GPIO36 GPIO 3.3V Standby S3_RXD Serial Receive Data PCH_GPIO37 GPIO 3.3V Standby S3_TXD Serial Transmit Data PCH_GPIO38 GPIO 3.3V Standby SIO_SERIRQ Super IO Serial IRQ for Interrupt Support PCH_GPIO39 GPIO 3.3V Standby Ground Ground Ground Ground Reference Manual ReadyBoard 910...

  • Page 37: Miscellaneous

    Real Time Clock (RTC) The ReadyBoard 910 contains a Real Time Clock (RTC). The CMOS RAM is backed up with a Lithium Battery. If the battery is not present, a battery-free boot option in the BIOS completes the boot process and resets the clock to the default date and time.

  • Page 38: Temperature Monitoring

    (without fan) for the PCH. User GPIO Signals The ReadyBoard 910 provides eight GPIO pins for custom use. The signals are routed to the CN13 header, and the enable and initialize values are set in the BIOS. For more information about GPIO pin operation, refer to the Programming Manual for the Super I/O controller at: http://www.smsc.com/main/catalog/sch311x.html...

  • Page 39: Serial Console

    Hardware Serial Console The ReadyBoard 910 supports the serial console (or console redirection) feature. This I/O function is provided by an ANSI-compatible serial terminal, or the equivalent terminal emulation software running on another system. This can be very useful when setting up the BIOS on a production line for systems that are not connected to a keyboard and display.

  • Page 40: Watchdog Timer

    BIOS implements interrupt 15 function 0C3h to manipulate the WDT. Power Interfaces The ReadyBoard 910 uses various voltages onboard and externally receives +12 volts through the external Power In (CN3) interface, which uses an 8-pin header with 0.165" (4.2 mm) pitch. The +12V is provided for the CPU Fan, System Fan, LVDS power, PCI-104 bus, and PCIe Mini Card power.

  • Page 41: Power On

    Power On The signals on this header allow the ATX power supply to be turned off (soft off) from the ReadyBoard 910 by operating system (OS) control. However, if you use a non-ATX power supply, then you will not have the soft off feature for sleep states normally provided by ATX power supplies.

  • Page 42: Power And Sleep States

    (awakened), restoring full operation to the ReadyBoard 910. In these various sleep states, the ReadyBoard 910 appears to be off, indicated by such things as no display on the attached monitor and no activity for the connected CD-ROM or hard drives. However, when the ReadyBoard 910 detects certain types of activity (i.e.
  • Page 43 All activity stops, except the internal clock, if there is a backup battery installed. Removing the power cord from the power source ensures all activity is stopped, except the internal clock. To go to a fully powered down state, the ReadyBoard 910 must either be powered on, or in a ♦...

  • Page 44: Wake Up Activities

    Chapter 3 Hardware Wake Up Activities The wake up events listed in Table 3-22 can be used to wake up the ReadyBoard 910 from any of the supported sleep states mentioned above. Table 3-22. Wake Up Activities and Conditions Signal/Device Condition...

  • Page 45: Chapter 4 Bios Setup

    This section describes how to enable the Remote Access in VGA mode and enter the BIOS setup through a serial terminal or PC. Turn on the power supply to the ReadyBoard 910 and enter the BIOS Setup Utility in VGA mode. Set the BIOS feature Serial Port Console to [Enable] under the Advanced menu.

  • Page 46: Oem Logo Screen (Splash)

    OEM Logo Screen (Splash) The ReadyBoard 910 BIOS supports a graphical logo screen, which can be customized by the user and an ADLINK Sales Representative and displayed when enabled through the BIOS Setup Utility. The graphical image can be a company logo or any custom image the user wants to display during the boot process.

  • Page 47: Bios Setup Menus

    BIOS Setup BIOS Setup Menus This section provides illustrations of the six main setup screens in the ReadyBoard 910 BIOS Setup Utility. Below each illustration is a bullet list of the screen’s submenus and setting selections. The setting selections are presented in brackets after each submenu or menu item, and the optimal default settings are presented in bold.

  • Page 48: Bios Advanced Setup Screen

    ACPI Sleep State [Suspend Disabled; S1 (CPU Stop Clock); S3 (Suspend to RAM)] ♦ Lock Legacy Resources [Disabled; Enabled] ♦ • CPU Configuration Intel(R) Core(TM) i7-XXXXLL CPU @ X.XXGHz ♦ Processor Stepping XXXxX ♦ Microcode Revision ♦ Max Processor Speed XXXXMHz ♦ Reference Manual ReadyBoard 910...
  • Page 49 Serial Port [Disabled; Enabled] Serial Port 3 Configuration ♦ • Serial Port [Disabled; Enabled] • H/W Monitor CPU Temperature +XX Degree C ♦ System Temperature +XX Degree C ♦ CPU Fan Speed ♦ SYS Fan Speed: ♦ ReadyBoard 910 Reference Manual...
  • Page 50 - Flow Control [None; Hardware RTS/CTS] - VT-UTF8 Combo Key Support [Disabled; Enabled] - Recorder Mode [Disabled; Enabled] - Resolution 100x31 [Disabled; Enabled] - Legacy OS Redirection Resolution [80x24; 80x25] COM1 ♦ • Console Redirection [Disabled; Enabled] Reference Manual ReadyBoard 910...
  • Page 51 - Parity [None] - Stop Bits [1] • Sandybridge PPM Configuration EIST [Disabled; Enabled] ♦ Turbo Mode [Disabled; Enabled] ♦ CPU C3 Report [Disabled; Enabled] ♦ CPU C6 Report [Disabled; Enabled] ♦ CPU C7 Report [Disabled; Enabled] ♦ ReadyBoard 910 Reference Manual...

  • Page 52: Bios Chipset Setup Screen

    Primary Display [Auto; IGFX; PCI] ♦ Internal Graphics [Disabled; Enabled] ♦ DVMT Pre-Allocated [0M; 32M; 64M; 96M; 128M; 160M; 192M; 224M; 256M; 288M; 320M; ♦ 352M; 384M; 416M; 448M; 480M; 512M] DVTM Total Gfx Mem [128M; 256M; MAX] ♦ Reference Manual ReadyBoard 910...
  • Page 53 [Disabled; Enabled] ♦ Restore AC Power Loss [Power Off; Power On; Last State] ♦ DC I2C Speed Control [100khz; 200khz; 400khz] ♦ USB Configuration ♦ • EHCI [Disabled; Enabled] • USB Ports Per-Port Disable Control [Disabled; Enabled] ReadyBoard 910 Reference Manual...

  • Page 54: Bios Boot Setup Screen

    5th Boot [CD/DVD; Hard Disk : Xxxxxxx; USB Floppy; USB CD/DVD; USB Hard Disk; ♦ USB Key; Network; UEFI; Disabled] 6th Boot [CD/DVD; Hard Disk : Xxxxxxx; USB Floppy; USB CD/DVD; USB Hard Disk; ♦ USB Key; Network; UEFI; Disabled] Reference Manual ReadyBoard 910...

  • Page 55: Bios Security Setup Screen

    ESC: Exit Version X.XX.XXXX. Copyright (C) 20XX American Megatrends, Inc. Figure 4-5. BIOS Security Setup Screen • Administrator Password [Create New Password] • User Password [Create New Password] • HDD Security Configuration HDD 0: XXXXXXXXXXX ♦ ReadyBoard 910 Reference Manual...

  • Page 56: Bios Save & Exit Setup Screen

    ♦ • Reset without saving? [Yes; No] • Save Options Save Changes ♦ • Save configuration [Yes; No] Discard Changes ♦ • Load Previous Values [Yes; No] Restore Defaults ♦ • Load Optimized Defaults [Yes; No] Reference Manual ReadyBoard 910...
  • Page 57 BIOS Setup Save as User Defaults ♦ • Save configuration? [Yes; No] Restore User Defaults ♦ • Restore User Defaults? [Yes; No] • Boot Override SATA: XXXXXXXXXXX ♦ Launch EFI Shell from file system device ♦ ReadyBoard 910 Reference Manual...
  • Page 58 Chapter 4 BIOS Setup Reference Manual ReadyBoard 910...

  • Page 59: Appendix A Technical Support

    Appendix A Technical Support ADLINK Technology, Inc. provides a number of methods for contacting Technical Support listed below in Table A-1. Requests for support through the Ask an Expert are given the highest priority, and usually will be addressed within one working day.
  • Page 60 Address: 84 Genting Lane #07-02A, Cityneon Design Centre, Singapore 349584 Tel: +65-6844-2261 Fax: +65-6844-2263 Email: singapore@adlinktech.com ADLINK Technology Singapore Pte. Ltd. (Indian Liaison Office) Address: No. 1357, "Anupama", Sri Aurobindo Marg, 9th Cross, JP Nagar Phase I, Bangalore - 560078, India Tel: +91-80-65605817 Fax: +91-80-22443548 Email: india@adlinktech.com...

  • Page 61: Index

    ..........35 mechanical specifications ......17 features ............5 memory description .............20 dimensions ............16 features .............5 map ..............22 features ............27 miscellaneous features .........31 pin-out list ............. 28 Oops! jumper (BIOS recovery) ......32 ReadyBoard 910 Reference Manual...
  • Page 62 Technical Support ..........53 slave addresses ..........33 temperature specification ............ 2 monitor ............32 SODIMM ............20 parameters ............. 15 specification references ......... 1 terminal emulation software Splash screen (user defined) ....... 40 serial console ..........33 Reference Manual ReadyBoard 910...
  • Page 63 Watchdog Timer (WDT) ........34 boot devices ............ 5 web sites features ............5 AMI BIOS 8 user’s guide ........2 pin out list ............. 26 Ethernet chip specification ......2 specification ............ 1 major chip specifications .........2 weight ..............16 width ..............16 ReadyBoard 910 Reference Manual...
  • Page 64 Index Reference Manual ReadyBoard 910...
