Chapter 2
NOTE
All dimensions are given in inches. Pin 1 is shown as a black pin (square or
round) on vertical headers or connectors in all illustrations. Black dots on right-
angle headers or connectors indicate pin 2.
The Compact Flash socket (J12) exceeds the PC/104 height limitation by 0.2
inches.

Power Specifications

Table 2-5
provides the power requirements for the 300 MHz and 800 MHz versions of the CoreModule 430.

Table 2-5. Power Supply Requirements

Parameter
Input Type
Peak In-rush Current
Idle Current
BIT Current (Typical)
Operating configurations:
In-rush operating configuration includes CRT video, 256MB DDR RAM, and power.
Idle operating configuration includes the in-rush configuration as well as on-board Compact Flash with
64MB card, and one keyboard.
BIT = Burn-In-Test. Operating configuration includes idle configuration as well as two serial port loop-
backs, one Ethernet connection, and four USB Compact Flash readers with 64MB Compact Flash.

Environmental Specifications

Table 2-6
provides the operating and storage condition ranges required for this module.

Table 2-6. Environmental Requirements

Parameter
Temperature
Operating
Extended (Optional)
Storage
Humidity
Operating
Non-operating

Thermal/Cooling Requirements

The CPU is the primary source of heat on the board. The 800 MHz version of the CoreModule 430 CPU is
designed to operate at its maximum speed and requires a heatsink (provided). The 300 MHz version of the
CoreModule 430 CPU does not require a heatsink.
CoreModule 430
Characteristics for 300 MHz CPU Characteristics for 800 MHz CPU
Regulated DC voltages
14.80A (74.00W)
1.30A (6.51W)
1.32A (6.58W)
Conditions
–20° to +70° C (–4° to +158° F)
–40° to +85° C (–40° to +185° F)
–55° to +85° C (–67° to +185° F)
5% to 90% relative humidity, non-condensing
5% to 95% relative humidity, non-condensing
Reference Manual
Product Overview
Regulated DC voltages
14.86A (74.30W)
1.42A (7.12W)
1.44A (7.19W)
