GPIO Interface
Provides two 6-pin interface headers

Supports a total of eight GPIO ports

Supports sample code in BSP QuickDrive

•
Utility Interface
Power Button

Reset Switch

Speaker

•
Miscellaneous
Real Time Clock (RTC) with external replaceable battery

Battery-free boot

Oops! Jumper support

Serial Console support

Watchdog Timer

Logo Screen (Splash)

SSD (Solid State Drive)

Hardware Monitor (voltage and temperature)

