Chapter 4

BIOS Setup Menus

This section provides illustrations of the six main setup screens in the CoreModule 920 BIOS Setup Utility.
Below each illustration is a bullet list of the screen's submenus and setting selections. The setting selections
are presented in brackets after each submenu or menu item, and the optimal default settings are presented in
bold. For more detailed definitions of the BIOS settings, refer to the AMI Aptio TSE User Manual:
http://www.ami.com/support/doc/AMI_TSE_User_Manual_PUB.pdf.
Table 4-1. BIOS Setup Menus
BIOS Setup Utility Menu
Main
Advanced
Chipset
Boot
Security
Save & Exit

Main BIOS Setup Screen

Aptio Setup Utility - Copyright (C) 20XX Amreican Megatrends, Inc.
Main
Advanced
BIOS Information
BIOS Vendor
Core Version
Compliancy
Project Version
Build Date and Time
System Language
System Date
System Time
Access Level
Version X.XX.XXXX. Copyright (C) 20XX American Megatrends, Inc.
CoreModule 920
Item/Topic
Language, Date, and Time
ACPI, CPU, SATA, GPIO, USB, Hardware Monitor, Serial Ports,
Serial Port Console
PCH I/O, System Agent
Boot up Settings, Boot Options, Boot Order
Setting or changing Passwords
Exiting with or without changing settings, loading and restoring
Optimal or User Defaults
Chipset
Boot
Security
American Megatrends
X.X.X.X
UEFI X.X; PI 1.2
CM920 REV: XXX
XX/XX/XXXX XX:XX:XX
[English]
[Xxx XX/XX/20XX]
[XX:XX:XX]
Administrator

Figure 4-1. Main BIOS Setup Screen

Reference Manual
Save & Exit
[Setting Description]
:
Select Screen
:
Select Item
Enter : Select
+/- : Change Opt.
F1 :
General Help
F2 :
Previous Values
F3 :
Optimized Defaults
F4 :
Save & Exit
ESC: Exit
BIOS Setup
