Chapter 3

USB Interface

The CoreModule 920 contains two root USB hubs and six functional USB ports. Four of the six USB ports
are routed through two 10-pin headers (H15 and J25), and the other two ports are routed through the
PCIe/104 interface connector. The PCH provides the USB function including the following features:
Supports USB v.2.0 EHCI and USB v.1.1 UHCI
Provides over-current detection status
Provides a fuse on board for over-current protection
Table 3-6
describes the pin signals of the USB0 and USB1 header which consists of 10 pins, in two rows,
with odd/even (1, 2) pin sequence, and 0.100" (2.54mm) pitch.

Table 3-6. USB0 and USB1 Interface Pin Signals (H15)

Pin #
Signal
1
USB-PWR_0
2
USB-PWR_1
3
CONN_USB0_N
4
CONN_USB1_N
5
CONN_USB0_P
6
CONN_USB1_P
7
USB_GND0
8
USB_GND1
9
USB_GND0
10
USB_GND1
Note: The shaded table cells denote power or ground.
Table 3-7
describes the pin signals of the USB2 and USB3 header, which consists of 10 pins in two rows,
with odd/even (1, 2) pin sequence, and 0.079" (2mm) pitch.
Table 3-7. USB2 and USB3 Interface Pin Signals (J25)
Pin #
Signal
1
USB-PWR_2
2
USB-PWR_3
3
CONN_USB2_N
4
CONN_USB3_N
5
CONN_USB2_P
6
CONN_USB3_P
7
USB_GND2
8
USB_GND3
9
USB_GND2
10
USB_GND3
Note: The shaded table cells denote power or ground.
CoreModule 920
Description
USB0 Power – VCC (+5V +/-5%) power goes to the port through an on-
board fuse. Port is disabled if this input is low.
USB1 Power – VCC (+5V +/-5%) power goes to the port through an on-
board fuse. Port is disabled if this input is low.
USB0 Port Data Negative
USB1 Port Data Negative
USB0 Port Data Positive
USB1 Port Data Positive
USB0 Ground
USB1 Ground
USB0 Ground
USB1 Ground
Description
USB2 Power – VCC (+5V +/-5%) power goes to the port through an on-
board fuse. Port is disabled if this input is low.
USB3 Power – VCC (+5V +/-5%) power goes to the port through an on-
board fuse. Port is disabled if this input is low.
USB2 Port Data Negative
USB3 Port Data Negative
USB2 Port Data Positive
USB3 Port Data Positive
USB2 Ground
USB3 Ground
USB2 Ground
USB3 Ground
Reference Manual
Hardware
27
