Chapter 2

Power Specifications

Table 2-5
provides the power requirements for the CoreModule 720.

Table 2-5. Power Supply Requirements

Parameter
Input Type
Typical In-rush Current
(Peak)
Typical Idle Current
BIT Current
Operating configurations:
In-rush operating configuration includes CRT monitor, 2GB memory, 8GB SSD, and power.
Idle operating configuration includes In-rush configuration as well as one SATA hard drive, USB
mouse and keyboard.
BIT (Burn-In-Test) operating configuration includes Idle configuration as well as four USB loop backs,
four serial ports with loop backs, and one Ethernet connection.

Environmental Specifications

Table 2-6
provides the most efficient operating and storage condition ranges required for this module.

Table 2-6. Environmental Requirements

Parameter
Temperature
Operating
Extended (Optional)
Storage
Humidity
Operating
Non-operating
16
600MHz E620T
Characteristics
Regulated DC voltages
16.24A (81.20W)
1.67A (8.34W)
2.72A (13.61W)
Conditions
–20° to +70° C (–4° to +158° F)
–40° to +85° C (–40° to +185° F)
–55° to +85° C (–67° to +185° F)
5% to 90% relative humidity, non-condensing
5% to 95% relative humidity, non-condensing
Reference Manual
1.3GHz E660T
Characteristics
Regulated DC voltages
16.24A (81.20W)
1.69A (8.43W)
2.85A (14.25W)
Product Overview
1.6GHz E680T
Characteristics
Regulated DC
voltages
16.24A (81.20W)
1.67A (8.33W)
2.97A (14.85W)
CoreModule 720
