Chapter 3
Table 3-11. LVDS Video Interface Pin Signals (J23) (Continued)
Pin #
Signal
13
LVDSA_DAT0_P
14
LVDSA_DAT0_N
15
LBKLT_CTL
16
LVDD_EN
17
LDDC_CLK
18
LDDC_DATA
19
LBKLT_EN
20
NC
Note: The shaded table cells denote power or ground.

Power Interface

The CoreModule 920 requires one +5 volt DC power source and provides a shrouded 10-pin, right-angle
header with 2 rows, odd/even pin sequence (1, 2), and 0.100" (2.54mm) pitch.
The power input header (J24) supplies the following voltage and ground directly to the module:
4.75VDC - 5.0VDC +/- 5%
Table 3-12. Power Interface Pin Signals (J24)
Pin
Signal
1
GND
2
+5V
3
GND
4
+12V
5
GND
6
+3.3V_PCI
7
GND
8
+5V
9
GND
10
+5V
Note: The shaded table cells denote power or ground.
CoreModule 920
Description
LVDS A DATA Positive Line 0
LVDS A DATA Negative Line 0
Panel Backlight Control
Enable Panel Power
Display Data Channel Clock
Display Data Channel Data
Enable Backlight Inverter
Not Connected
Descriptions
Ground
+5 Volts
Ground
+12 Volts routed to PC/104, PC/104-Plus, and LVDS interfaces
Ground
+3.3 Volts routed to PCI
Ground
+5 Volts
Ground
+5 Volts
Reference Manual
Hardware
31
