Chapter 2
Header, Connector, and Socket Definitions
Table 2-2
describes the headers, connectors, and socket of the CoreModule 920 shown in
Table 2-2. Module Header and Connector Descriptions
Header #
H11 – GLAN1
H15 – USB (0-1)
H16 – COM2
J2 – LED - GLAN1
J3 – LED - GLAN2
J5 – PCIe/104
J6 – PCIe/104
J7 – PCI-104
J8 – HDMI (Micro)
J10 – SATA0
J12 – Battery
J13 – SATA1
J14 – GLAN2
J17 – VGA
J18 – COM1
J21 – Utility
J22 – Fan
J23 – LVDS
J24 – Power
14
Board
Description
Access
Top
10-pin, 0.100" (2.54mm) header for Gigabit Ethernet port 1
(JIH JVE, 21N22564-10S10B-01G-6/3-G)
Top
10-pin, 0.100" (2.54mm) header for USB 2.0 ports 0-1
(JIH JVE, 21N22564-10S10B-01G-6/3-G)
Top
10-pin, 0.100" (2.54mm) header for serial port 2
(JIH JVE, 21N22564-10S10B-01G-6/3-G)
Top
4-pin, 0.049" (1.25mm) shrouded, single-row header for Gigabit
Ethernet port 1 LED (SMP Technology, W125-0410-310-Z)
Top
4-pin, 0.049" (1.25mm) shrouded, single-row header for Gigabit
Ethernet port 2 LED (SMP Technology, W125-0410-310-Z)
Top
156-pin, 0.025" (0.64mm) standard PCI Express connector for
SMBus, USB 2.0, PCIe x1, and PCI interfaces
(SAMTEC, ASP-129637-03)
Bottom
156-pin, 0.025" (0.64mm) standard PCI Express connector for
SMBus, USB 2.0, PCIe x1, and PCI interfaces
(SAMTEC, ASP-129646-03)
Top/Bottom
120-pin, 0.079" (2mm) standard PCI-104 connector for PCI
interfaces (EPT, 264-60303-12)
Top
19-pin, 0.016" (0.04mm), standard micro-connector for HDMI
video port (MOLEX, 46765-0001)
Top
7-pin, 0.050" (1.27mm) standard connector for SATA 3.0 port 0
(WIN WIN, WATM-07DBN4B2B8UW)
Top
2-pin, 0.049" (1.25mm) shrouded header for power from external
battery (REGO, 830-1251-02STD-3.2)
Top
7-pin, 0.050" (1.27mm) standard connector for SATA 3.0 port 1
(WIN WIN, WATM-07DBN4B2B8UW)
Top
10-pin, 0.079" (2mm) shrouded header for Gigabit Ethernet port 2
(HIROSE, DF11-10DP-2DSA)
Top
10-pin, 0.079" (2mm) header for VGA video port
(JIH, 21N22050-10S10B-01G-4/2.8-G)
Top
10-pin, 0.079" (2mm) shrouded header for serial port 1
(HIROSE, DF11-10DP-2DSA)
Top
6-pin, 0.079" (2mm) single-row header for Power Button, Reset
Switch, and Speaker (SAMTEC, TMM-106-03-L-S)
Top
3-pin, 0.079" (2mm) shrouded header for power to external fan
(NELTRON, 2417SJ-03)
Top
20-pin, 0.079" (2mm) shrouded header for LVDS video port
(HIROSE, DF11-20DP-2DSA)
Top
10-pin, 0.100" (2.54mm) shrouded, right-angle header for
supplying external power to the board
(FCI, 78207-210HLF)
Reference Manual
Product Overview
Figure
2-6.
CoreModule 920
