LL TIM Generic Driver
TIM_LL_EC_ICPSC.This feature can be modified afterwards using unitary function
LL_TIM_IC_SetPrescaler().
uint32_t LL_TIM_IC_InitTypeDef::ICFilter
Specifies the input capture filter. This parameter can be a value of
TIM_LL_EC_IC_FILTER.This feature can be modified afterwards using unitary
function LL_TIM_IC_SetFilter().
67.1.4

LL_TIM_ENCODER_InitTypeDef

Data Fields
uint32_t EncoderMode
uint32_t IC1Polarity
uint32_t IC1ActiveInput
uint32_t IC1Prescaler
uint32_t IC1Filter
uint32_t IC2Polarity
uint32_t IC2ActiveInput
uint32_t IC2Prescaler
uint32_t IC2Filter
Field Documentation
uint32_t LL_TIM_ENCODER_InitTypeDef::EncoderMode
Specifies the encoder resolution (x2 or x4). This parameter can be a value of
TIM_LL_EC_ENCODERMODE.This feature can be modified afterwards using unitary
function LL_TIM_SetEncoderMode().
uint32_t LL_TIM_ENCODER_InitTypeDef::IC1Polarity
Specifies the active edge of TI1 input. This parameter can be a value of
TIM_LL_EC_IC_POLARITY.This feature can be modified afterwards using unitary
function LL_TIM_IC_SetPolarity().
uint32_t LL_TIM_ENCODER_InitTypeDef::IC1ActiveInput
Specifies the TI1 input source This parameter can be a value of
TIM_LL_EC_ACTIVEINPUT.This feature can be modified afterwards using unitary
function LL_TIM_IC_SetActiveInput().
uint32_t LL_TIM_ENCODER_InitTypeDef::IC1Prescaler
Specifies the TI1 input prescaler value. This parameter can be a value of
TIM_LL_EC_ICPSC.This feature can be modified afterwards using unitary function
LL_TIM_IC_SetPrescaler().
uint32_t LL_TIM_ENCODER_InitTypeDef::IC1Filter
Specifies the TI1 input filter. This parameter can be a value of
TIM_LL_EC_IC_FILTER.This feature can be modified afterwards using unitary
function LL_TIM_IC_SetFilter().
uint32_t LL_TIM_ENCODER_InitTypeDef::IC2Polarity
Specifies the active edge of TI2 input. This parameter can be a value of
TIM_LL_EC_IC_POLARITY.This feature can be modified afterwards using unitary
function LL_TIM_IC_SetPolarity().
uint32_t LL_TIM_ENCODER_InitTypeDef::IC2ActiveInput
Specifies the TI2 input source This parameter can be a value of
TIM_LL_EC_ACTIVEINPUT.This feature can be modified afterwards using unitary
function LL_TIM_IC_SetActiveInput().
uint32_t LL_TIM_ENCODER_InitTypeDef::IC2Prescaler
Specifies the TI2 input prescaler value. This parameter can be a value of
TIM_LL_EC_ICPSC.This feature can be modified afterwards using unitary function
LL_TIM_IC_SetPrescaler().
