UM1940

LL_TIM_IC_EnableXORCombination

Function name
Function description
Parameters
Return values
Notes
Reference Manual to
LL API cross
reference:

LL_TIM_IC_DisableXORCombination

Function name
Function description
Parameters
Return values
Notes
Reference Manual to
LL API cross
reference:

LL_TIM_IC_IsEnabledXORCombination

Function name
Function description
Parameters
Return values
Notes
Reference Manual to
LL API cross
reference:
CCER CC3NP LL_TIM_IC_GetPolarity
CCER CC4P LL_TIM_IC_GetPolarity
CCER CC4NP LL_TIM_IC_GetPolarity
__STATIC_INLINE void LL_TIM_IC_EnableXORCombination
(TIM_TypeDef * TIMx)
Connect the TIMx_CH1, CH2 and CH3 pins to the TI1 input (XOR
combination).
TIMx: Timer instance
None:
Macro IS_TIM_XOR_INSTANCE(TIMx) can be used to check
whether or not a timer instance provides an XOR input.
CR2 TI1S LL_TIM_IC_EnableXORCombination
__STATIC_INLINE void LL_TIM_IC_DisableXORCombination
(TIM_TypeDef * TIMx)
Disconnect the TIMx_CH1, CH2 and CH3 pins from the TI1 input.
TIMx: Timer instance
None:
Macro IS_TIM_XOR_INSTANCE(TIMx) can be used to check
whether or not a timer instance provides an XOR input.
CR2 TI1S LL_TIM_IC_DisableXORCombination
__STATIC_INLINE uint32_t
LL_TIM_IC_IsEnabledXORCombination (TIM_TypeDef * TIMx)
Indicates whether the TIMx_CH1, CH2 and CH3 pins are
connectected to the TI1 input.
TIMx: Timer instance
State: of bit (1 or 0).
Macro IS_TIM_XOR_INSTANCE(TIMx) can be used to check
whether or not a timer instance provides an XOR input.
CR2 TI1S LL_TIM_IC_IsEnabledXORCombination
DocID028236 Rev 2
LL TIM Generic Driver
1195/1371
