3.2.11 Charging Station Problems
Problem Encountered
Robomower does not leave
the Charging Station for
operation at the time set in
the Weekly Program
Robomower records the information and the reason in case it will not depart from the Docking Station.
Usually a '+' sign is appeared below the active day, but if from some reason the mower does not depart on time from the
Docking Station, the '+' sign is changed with one of the following:
Probable Cause/Event
- Confirm the time in the mower is set
correctly (day and hour)
- Low battery voltage
- 'Auto depart' is set to 'off' ('Manual
depart' is displayed when the mower is
in the Docking Station)
Character
+ Active day
Skipped due to rain
R
(Robomow did not departe from the Docking Station at the
scheduled time due to rain detection)
Docked before time due to rain
(Robomow did not complete the operation and drove back to
r
the Docking Station due to rain detection during the
operation)
Skipped due to low battery voltage
B
(Robomow did not departe from the Docking Station at the
scheduled time due to low battery voltage)
Docked before time due to low battery voltage
(Robomow did not complete the operation and drove back to
b
the Docking Station due to low battery voltage – relevant only
when 'Working time' is set)
Skipped because there was no contact with Docking Station
or there was no charging voltage (power break or mower
D
which is placed out of the Docking Station) at the scheduled
depart time
Skipped due to user choice (for example if the user chose the
U
'skip next depart' option or set the 'Auto depart' to 'off')
Skipped because there was no charging at the scheduled
departs time, although there was voltage (usually when the
C
Robomow is in the Docking Station, but the Manual Controller
is not in its place).
Corrective/User Action
- Set the time (See paragraph 4.2 in the
Operating and Safety Manual)
- Confirm there are minimum 16 hours of
charging in the Docking Station before the
next scheduled depart
- Change the setting of the 'Auto depart' to 'on'
(See paragraph 6.3 in the Operating and
Safety Manual)
Meaning
