5.5.9 Auto Restart

This option enables to set the cases in which Robomow restarts the operation automatically
within an hour after it has stopped during the operation.

5.5.9.1 Drive Overload

If the mower stops with the following 'Drive overload - cooling, wait...'(10 min above
100 or 1 sec above 105), it will stay awake for up to 60 minutes with the displayed
message and blinking operating light. If the mower cooled down to allowed temperature
that enables the operation
operation from the point he has stopped.

5.5.9.2 Mow Overload

If the mower stops with the following 'Mow overload - cooling, wait...'(10 min above 90
or 1 sec above 100), it will stay awake for up to 60 minutes with the displayed message
and blinking operating light. If the mower cooled down to allowed temperature that
enables the operation
operation from the point he has stopped.

5.5.9.3 Power Break

Electrical power interruption - In every signal interruption the RL1000 will stop with
'Waiting for signal...' message. If the signal comes back within 60 minutes from the
stop, the mower will restart the operation automatically, otherwise it will stop with 'No
wire signal – press GO'. The Operating Lamp is blinking all the time that the mower is
waiting.

5.5.10 Special Display

Choosing the 'Special display' option enables to display the relevant parameters to tested
process
(such as temp, volt and sensor readings) and to perform detailed diagnostics. After a specific
display is selected use the CANCEL ('C') button to toggle between normal and special
display,
and the STOP button to terminate the special display.
5.5.10.1 Charging display
In this display the LCD will display the following information:
1.Charging stage 1.Charging stage 1.Charging stage
5.Charging time 6.Charging FET d2a 7.Charging FET temp. 8.Ambience temp. 9.Charging enable flag 5.Charging time 6.Charging FET d2a 7.Charging FET temp. 8.Ambience temp. 9.Charging enable flag 5.Charging time 6.Charging FET d2a 7.Charging FET temp. 8.Ambience temp. 9.Charging enable flag
1. Charging stage.
The stage of the charging process.
2. Battery voltage.
Battery voltage in volts.
3. Charger voltage.
Power Supply voltage in volts.
(Drive - 85 Celsius), the mower will automatically renew the
(Mow - 80 Celsius), the mower will automatically renew the
2.Battery voltage 2.Battery voltage 2.Battery voltage 3.Charger voltage 3.Charger voltage 3.Charger voltage 4.Docking state 4.Docking state 4.Docking state
