Friendly Robotics robomower RL350 Service Manual page 28

1.6.1 Spare Parts – sorted by item number (con.)
Friendly P /N
Friendly P /N
#
(2005)
(2006)
39 GEN0104A GEN0104A Wheel Cup (gray)
39 GEN0201A GEN0201A Wheel Cup (black)
40 GEN0146A GEN0146A Main board rubber holder
41 CPS0007A CPS0007A Wire twist lock
42 GEN0171A GEN0171A Motor shading
43 ESBC021C ESBC021C Connectors Board
44 SPP0004C SPP0004B
45 GEN0142A GEN0142A Connector's cover
46 GEN0145A GEN0145A Pivot for manual controller's tray
47 LMP0004A LMP0004A Operating bulb bayonet 24v/4w
48 SCR0029A SCR0029A Screw DIN 7981C A2 4.2x25 (Docking Station)
49 SPP0028B SPP0028A
50 SCR0027A SCR0027A Screw WN 1412 KA25x8 (Docking Board)
51 GEN0176A GEN0176A Docking Board seal
52 GEN0218A GEN0218A Push button for Docking Board
53 GEN0223A GEN0223A Fastening Stakes for the Charging Station
54 GEN0217B GEN0217B D. Station Connectors Cover (Green)
55 SPP0009B SPP0009A
56 SPP0015A SPP0015A
57 GEN0122A GEN0122A Shafts clamp (gear)
58 MSB0077A MSB0077A Slider assembly
59 MSB0079A MSB0079A Gear spline + bearing
60 GEN0101A GEN0101A Odometer magnet
61 SCR0025A SCR0025A Screw for RL motors
62 GEN0132A GEN0132A Battery cover
63 GEN0131A GEN0131A Battery Case
64 GEN0130A GEN0130A Contact leaf-battery
65 PWS0004A PWS0004A 230VAC Out Door Power Supply (EUR)
65 PWS0005A PWS0005A 115VAC Out Door Power Supply (US)
65 PWS0006A PWS0006A 230VAC Out Door Power Supply (UK)
66 PWS0001A PWS0001A 230VAC power supply -Europe
66 PWS0002A PWS0002A 230VAC power supply - UK
66 PWS0003A PWS0003A 115VAC power supply - US
67 CBL0037A CBL0037A
67 CBL0038A CBL0038A
67 CBL0039A CBL0039A
68 UNT0016A UNT0016A Power Pack external charging adaptor
69 FUS0021A FUS0021A
70 FUS0015A FUS0015A
71 FUS0003A FUS0003A
72 FUS0012A FUS0012A
73 MRK0025B MRK0025B 5 hrs. Perimeter Switch
74 GEN0156A GEN0156A Perimeter switch back cover
75 GEN0175A GEN0175A Stake for perimeter switch
76 BAT0003A BAT0003A
77 CON0054A CON0054A Plot connector
78 MSB0090A MSB0090A Contact strip front assembly
79 MSB0091B MSB0091B Contact strip rear assembly
80 RNG0031A RNG0030A Washer M10x15 (BN 739)
81 GEN0117A GEN0117A Adjusting bolt
82 SPP0005B SPP0005B
Part Description
Spare part gear case
Charging Station Board (includes screws, tact switch
cover and push button)
Gear Shafts replacement kit
Gear Frame (+ GEN0202A and DOC0056A)
External charger cord - UK
External charger cord - US
External charger cord - EUR
Fuse 5x20 10A 125V (External Charger)
Fuse mini blade 5A
Fuse AT blade 30A 32V
Fuse AT blade 1A 32V
Battery holder for perim.switch with screws
Drop off board + holder
Appears in
No. of
Exploded views
parts
No.
1.2.1 2
1.1.3 & 1.2.1 2
1.2.2 4
1.2.2
1.2.2 5
1.2.2 & 1.4.2 1
1.2.2 & 1.2.5 1
1.2.3 1
1.2.3 2
1.2.3 1
1.2.4 5
1.2.4 1
1.2.4 8
1.2.4 1
1.2.4 1
1.2.4 5
1.2.4 3
1.2.5 1
1.2.5 1
1.2.5 2
1.2.5 2
1.2.5 2
1.2.5 4
1.2.5 8
1.2.6 1
1.2.6 1
1.2.6 2
1.2.6 1
1.2.6 1
1.2.6 1
1.2.6 1
1.2.6 1
1.2.6 1
1.2.6 1
1.2.6 1
1.2.6 1
1.2.6 1
1.2.7 & 1.3 1
1.2.7 & 1.3 1
1.2.7 & 1.3 1
1.2.7 & 1.3 1
1.2.8 1
1.2.8 1
1.2.8 1
1.2.8 1
1.2.8 1
1.2.8 1
1.2.8 1
1.2.10 1
1.2.10 1
1.2.10 1
1
25
