Friendly Robotics robomower RL350 Service Manual page 60

Problem analysis flow charts – Table of Contents
3.2.1 Installation and Setup
3.2.1.1 Wire disc (P. Switch)
3.2.1.2 Replace battery (P. Switch)
3.2.1.3 P. Switch does not operate
3.2.2 Power & Charging
3.2.2.1 Robomower does not 'Wake up'
3.2.2.2 Charging Failure
3.2.2.3 Check Power
3.2.2.4 No Charging indication
3.2.2.5 Short run time
3.2.3 Mowing
3.2.3.1 'Check mow height' message
3.2.3.2 Uncut lane left behind the Robomower
3.2.3.3 Mowing motors do not start but the Robomower moves on the lawn
3.2.3.4 'Mow overload – Cooling, wait...' message
3.2.3.5 Cannot start mowing motors in manual mode
3.2.3.6 Poor mulching
3.2.4 Edge
3.2.4.1 Does not complete Edge
3.2.4.2 Robomower is not centered on the perimeter wire
3.2.4.3 Robomower is 'zigzagging' as it edges (weaves left and right)
3.2.5 Automatic Mowing
3.2.5.1 Many patches of uncut grass remain on the lawn
3.2.5.2 Robomower ignores areas
3.2.5.3 Stops with no message
3.2.5.4 Robomower keeps going back and forth on the same lines
3.2.5.5 Poor direction keeping – Robomower does not move in straight lines
3.2.5.6 Wire crossing
3.2.6 Manual Controller
3.2.6.1 One or more of the Manual Controller buttons do not respond
3.2.6.2 Manual Controller display does not change to 'Zone A' / 'Dock zone'
when placing it in its place.
3.2.7 Drive
3.2.7.1 'Drive overload – press GO' message
3.2.7.2 'Drive overload – Cooling, wait...' message
3.2.7.3 'Drive Problem' message
3.2.8 Front Wheel
3.2.8.1 'Front wheel problem' message
3.2.9 Bumpers
3.2.9.1 'Front /Rear Bumper Pressed' message
3.2.9.2 'Front /Rear Bumper disc.' message
3.2.9.3 Bumper sounds without hitting an obstacle
3.2.9.4 Bumper is not responding when hitting an obstacle
7
7
9
10
11
11
12
13
14
15
16
16
16
16
16
17
17
18
18
19
19
20
20
20
21
22
22
23
24
24
24
25
25
25
26
27
27
28
28
29
29
30
3
5
