(RL500: On Manual/settings press green button, scroll up to Service key, insert 12321,
green button, Confirm, green button and the menu will jump to Diagnostics. Green button to
get into diagnostic mode and now scroll down or up to the wanted test).
Calibration, Tests and Settings
Various calibrations, tests and settings are found under the 'Service' menu that may be
used by the technician. Each of these tests is selectable by simply scrolling through the menu.
After completing work in a specific area, perform the test shown in the procedure and then
perform the General Test outlined in Section 5.1. This will insure that the repair has been
done properly and that the unit functions satisfactorily.
The results of some tests will be a pass or fail while others will display a fault code
number. Refer to the fault code in Section 5.6 Diagnostics Fault Codes.
Please follow the instructions for each test carefully. At the end of each test press the 'C'
button to exit. Continual pressing of the 'C' button will move you up through the menu levels,
until you arrive at the Main Menu.
Too busy, lack of time or do not understand the test fully: At least operate the Robomow
on the test area in automatic mode, to make sure it is fully operational. Testing it in manual
mode for driving or manual mowing is not satisfactory at all prior to handing it back to the
customer. The Robomow has built in warning and indication system that will pop up on the
display in Automatic mode in case you forgot to perform any of the needed calibrations after
service.
