3.0 Docking Options (RL1000 only)
3.1 Weekly Program
3.1.1 Set Weekly Program
One of the advantages of having a docking station for the Robomow is the ability to set
an automatic weekly program. The user can set the weekly program at the beginning of a
season and not worry about mowing again all season long.
Four parameters are required to be selected: Day/s, Work time, hour/s, operating mode/s.
Select the day or days, the work time and the time in which you would like the mower to
automatically depart and mow your lawn. Also select whether to have the edge mowed or
not.
If 'Learn edge' is done, another option in the weekly program is available to the user – to
set the 'Entry point' per specific day.
While the mower is docked, the next departure scheduled will be displayed at the top
right corner of the LCD. It will display the day of the next departure, the time and mode.
3.1.2 Display Program
Select this option in order to view the weekly program. The days of the week will be
displayed on the LCD (M, T, W, T, F, S, S) and a + or – under each letter. A '+'
represents an active day, meaning that the mower will mow during that day, at the time
scheduled.
3.2 Time
The first step before setting the weekly program is to set the current time: day of the week and
time (hours & minutes). Note that the clock is on a 24-hour military time scale.
This feature is relevant only if a weekly program has been set.
While the mower is docked, the current time will be displayed at the top left corner of the LCD.
Note that whenever the power pack is removed from the mower, it is required to set the time.
3.3 Entry Points
'Entry point' is defined as the point, where the mower leaves the Edge and turn into the lawn to
mow the inner area. In order to ensure better area coverage in mowing, the mower has default of
three different entry points. The 'Entry points' option enable to set different entry points from
those set by the factory to your lawn.
3.3.1 Set Entry Points
It is possible to set up to four points (includes the Docking Station itself, which is always
defined as entry point number one and cannot be canceled).
3.3.2 Back to Default
Selecting 'Back to default' restores the factory default entry points – there is no distance in the
memory and the mower should complete the lawn's edge at least once before it will use the
default of 30% and 60% percentages of the perimeter as entry points.
3.3.3 Entry Points (on/off)
Allows user not to use the entry points. When setting the 'Entry points' to 'off' the mower will
start the mowing of the inner area always from the Docking Station.
3.4 Auto Depart
Allows user to shut off the weekly program when setting the 'Auto depart' to 'off'.
