2.0 Information
2.1 Total time
A very important information menu item, this shows the total operating time of the mower. This
is valuable information used for warranty and repair services. It can also indicate the usage model
of the mower, for example using the mower on multiple properties instead of for homeowner use
as it is designed. This number will only reset when a main board has been replaced. It is also a
required line entry for a warranty claim.
2.2 Bat. run time
The left number indicates the last battery run time from GO pressing till 'Recharge battery'
message is displayed and the right number indicates the battery voltage at the beginning of the
operation (measured when the GO is pressed).
2.3 Battery voltage
Displays the current voltage of the power pack.
2.4 Temperature
Displays the ambience temperature in the mower.
2.5 Main Board
Main Board will display the version of CPU used in this particular mower. This is essentially an
information menu, but can be used in the event an issue is found to only apply to one particular
CPU.
2.6 Software version
Identifies the software version operating in this mower. An information menu, but can be
important if a particular issue is found and it applies to only a specific version of software.
2.7 Charging voltage
Displays the charging voltage.
2.8 Charging temp.
Displays the charging temperature (measured on the Main Board).
2.9 Last stop cause
Displays the last 10 stop cause numbers (refer to Last Stop Cause Table in paragraph 5.7).
