1.1.3 Robomow internal views
17
Front left
Wire sensor
SPP0018A
12
Left Mowing
Motor
MSB0065B
25
Main Board
SPP0019B
24
Odometer board L
ESBC025C
23
Drive Motor
SPP0008B
Rear left
Wire sensor
SPP0018A
17
82
Drop-off Board
SPP0005B
Ground
clearance limiter
GEN0202A
22
Figure 1.1.3 Internal view
1
&
27 28
Front wheel stopper
GEN0207A
& Spring GEN0208A
Thermistor Kit
SPP0020A
21
17
Front right
Wire sensor
SPP0018A
12
Right Mowing
Motor
MSB0065B
12
Center
Mowing Motor
MSB0065B
18
Cover-base seal ring
GEN0182A
Odometer board R
ESBC024C
Battery contacts
(RL side)
SPP0014A
20
Rear right
Wire sensor
SPP0018A
17
4
19
