6.3.9 Auto Restart
This option enables to set the cases in which Robomow restarts the operation automatically within
an hour after it has stopped during the operation.
6.3.9.1 Drive Overload
If the mower stops with the following 'Drive overload - cooling, wait...'(10 min above 100
or 1 sec above 105), it will stay awake for up to 60 minutes with the displayed message and
blinking operating light. If the mower cooled down to allowed temperature that enables the
operation (Drive - 85
point he has stopped.
6.3.9.2 Drive Overload
If the mower stops with the following 'Mow overload - cooling, wait...'(10 min above 90 or
1 sec above 100), it will stay awake for up to 60 minutes with the displayed message and
blinking operating light. If the mower cooled down to allowed temperature that enables the
operation (Mow - 80
point he has stopped.
6.3.9.3 Power Break
Electrical power interruption - In every signal interruption the RL1000 will stop with
'Waiting for signal...' message. If the signal comes back within 60 minutes from the stop, the
mower will restart the operation automatically, otherwise it will stop with 'No wire signal –
press GO'. The Operating Lamp is blinking all the time that the mower is waiting.
6.3.10 Special Display
Choosing the 'Special display' option enables to display the relevant parameters to tested process
(such as temp, volt and sensor readings) and to perform detailed diagnostics. After a specific
display is selected use the CANCEL ('C') button to toggle between normal and special display,
and the STOP button to terminate the special display.
6.3.10.1 Charging display
In this display the LCD will display the following information:
1.Charging stage 1.Charging stage 1.Charging stage
5.Charging time 6.Charging FET d2a 7.Charging FET temp. 8.Ambience temp. 9.Charging enable flag 5.Charging time 6.Charging FET d2a 7.Charging FET temp. 8.Ambience temp. 9.Charging enable flag 5.Charging time 6.Charging FET d2a 7.Charging FET temp. 8.Ambience temp. 9.Charging enable flag
1. Charging stage.
The stage of the charging process.
2. Battery voltage.
Battery voltage in volts.
3. Charger voltage.
Charger voltage in volts.
Celsius), the mower will automatically renew the operation from the
Celsius), the mower will automatically renew the operation from the
2.Battery voltage 2.Battery voltage 2.Battery voltage 3.Charger voltage 3.Charger voltage 3.Charger voltage 4.Docking state 4.Docking state 4.Docking state
