3.2.4.1
Robomow does
not complete the
Edge
If the problem appears in
Dock zone, please refer to
section 3.2.11.6 (page 3.33)
'Learn edge' is done per
zone – choosing the wrong
zone in the LCD will cause
the Robomower to perform
different edge distance.
3.2.4 Edge Problems
Does the
Robomow leave
the edge or stop
displaying an error
message?
Observe mower
on edge – is wire
properly placed to
prevent bumper
activation while in
edge?
Confirm Robomow is
operated in the right
zone
Choose 'Set default edge'
under 'User preferences'
menu and retest
Access 'Learn Edge' in menu (under 'User
Preferences>Zones setup') and perform the
following:
Place the mower several feet from the Edge
Choose 'Learn Edge' (if the user has more
than one zone activated for operating time,
be sure to select 'Learn edge' in the zone
where the problem exists.
Press 'GO' to initiate the operation (the
mower blades will not operate in this feature).
At the completion of one full edge operation,
press the 'Stop' button.
The process in now complete and edge
mowing will now operate completely.
Stops
displaying
an error
Leaves the
edge and
starts to mow
NO
YES
Refer to the error
message in the LCD
(See paragraph 3.1)
Adjust perimeter wire in
areas where bumper is
being activated
Perform 'Edge termination
test' under the
'Service>Tests' menu – it
should point about the
reason which causes the
mower to leave the edge
before it completed.
