Technical Service Bulletin
Date: Sep 20, 2005
Product Model:
All
Serial Range:
All
S.W. version (Flash) Replacement Instructions
The following instructions are in addition to the standard procedure defined in the Service Guide.
Spare Part
Flash
(S.W. version)
SPP0033C/35C/
36C/40C/41C
RL850 - compatible with Main Board
3.2-06
SPP0101A-
105A
RL1000 - compatible with Main Board
4.1-06
SPP0027A
3.2a
PRG0005A
Service version supporting Main Board
3.2i
(Service
'Charging failure' message received
Bulletin
#RL0305-07)
NOTE: After replacing a flash (S.W version) it is required to perform the following steps:
1. 'Factory defaults' under the 'Service>Settings' menu.
2. The mower will display 'Are you sure?' - Press the 'GO' button to confirm (it will reset).
3. Under 'Service' perform 'Learn wire sensors' (Section 5.3.4 in the Service Guide)
4. Under 'Service' perform 'Edge Calibration' (Section 5.3.3 in the Service Guide)
5. Under 'Service' perform 'Set country' (Section 5.3.1 in the Service Guide).
6. Under 'Service' perform 'DK Calibration' (Section 5.3.2 in the Service Guide).
Part Numbers:
Countries Affected:
When to use?
The most updated S.W version for
ESBC050B
The most updated S.W version for
ESBC050B
The most updated S.W version
compatible with Main Board
ESB0019B/C.
ESBC045B only (especially for
during the charging process)
Service Bulletin #RL0536-11
All Software Version
All
Main Board
SPP0019B
Main Board label
is marked with
ESBC050B
SPP0019B
Main Board label
is marked with
ESBC050B
Main Board label
is marked with
ESB0019B/C
Main Board label
is marked with
ESBC045B
Manual
Controller
All
All
MSB0112A
MSB0114A
(Does not support
MSB0117A to
MSB0019A)
MSB0112A
MSB0114A
(Does not support
MSB0117A to
MSB0019A)
