3. Ambience temperature (ºC).
Ambience temperature in ºC.
4. Mow temperature (a2d).
Mow temperature in a2d.
Otherwise - over current.
5. Right drive temperature (a2d).
Right drive temperature in a2d.
6. Charging FET temperature (ºC).
Charging FET temperature in ºC.
6.3.10.4 Edge
In this display the LCD will display the following information:
1.DK angle (degrees) 1.DK angle (degrees) 1.DK angle (degrees)
4.Moving toward DS 4.Moving toward DS 4.Moving toward DS
1. DK angle.
DK angle in degrees.
2. DK quarters.
DK quarters during edge.
3. High edge speed.
Indicates if high speed during edge is enabled.
0 – Disabled
1 – Enabled
4. Moving towards ds.
Indicates if we are moving towards the Charging Station.
0 – No
1 - Yes
5. Wire sensors state:
0 - all wire sensors are inside the garden
1 - forward right sensor outside the garden
2 - backward left sensor outside the garden
4 - forward left sensor outside the garden
5 - forward left and right sensors outside the garden
6 - forward left and backward left sensors outside the garden
7 - forward left forward right and backward left sensors outside the garden
8 - backward right sensor outside the garden
9 - forward right and backward right sensors outside the garden
10 - backward left and right sensors outside the garden
11 - backward left backward right and forward right sensors outside the garden
13 - forward left forward right and backward right sensors outside the garden
14 - backward left backward right and forward left sensors outside the garden
15 - all wire sensors are outside the garden
6. Distance from right turn in meters
2.DK quarters 2.DK quarters 2.DK quarters
5.Wire sensors state 5.Wire sensors state 5.Wire sensors state
3.High edge speed 3.High edge speed 3.High edge speed
6.Dist from right turn (meters) 6.Dist from right turn (meters) 6.Dist from right turn (meters)
