Friendly Robotics robomower RL350 Service Manual page 30

1.6.2 Spare Parts – sorted by Friendly part number
Friendly P/N
Friendly P/N
#
(2006)
BAT0003A BAT0003A
76
67 CBL0037A CBL0037A
67 CBL0038A CBL0038A
67 CBL0039A CBL0039A
77 CON0054A CON0054A Plot connector
41 CPS0007A CPS0007A Wire twist lock
116 CPS0013A CPS0013A
126 CPS0014A
110 DOC0008B DOC0008B RoboRuler
86 DOC0015D DOC0015C RL Operating Manual (En)
111 DOC0051E DOC0051D RL Service Guide Hard Copy (En)
112 DOC0053C DOC0053B RL Service Guide CD (En)
113 DOC0065B
86 DOC0076B DOC0076A RL1000 + Docking Manual (En)
35 ESB0022B ESB0022B
95 ESB0031A ESB0031A
43 ESBC021C ESBC021C Connectors Board
19 ESBC024C ESBC024B Odometer Board R
24 ESBC025C ESBC025B Odometer Board L
71 FUS0003A FUS0003A
72 FUS0012A FUS0012A
70 FUS0015A FUS0015A
69 FUS0021A FUS0021A
121 GEN0067A GEN0067A Fast charger 115/230V (without cord)
1 GEN0094A GEN0094A RL Yellow cover
13 GEN0095A GEN0095A RL plastic base
60 GEN0101A GEN0101A Odometer magnet
39 GEN0104A GEN0104A Wheel Cup (gray)
83 GEN0116A GEN0116A Drop off flag
81 GEN0117A GEN0117A Adjusting bolt
99 GEN0118A GEN0118A Front Wheel Click Spring ('02 configuration)
57 GEN0122A GEN0122A Shafts clamp (gear)
64 GEN0130A GEN0130A Contact leaf-battery
63 GEN0131A GEN0131A Battery Case
62 GEN0132A GEN0132A Battery cover
36 GEN0133A GEN0133A Magnet for Manual Controller
34 GEN0140A GEN0140A Sealing cup
45 GEN0142A GEN0142A Connector's cover
46 GEN0145A GEN0145A Pivot for manual controller's tray
40 GEN0146A GEN0146A Main board rubber holder
97 GEN0148A GEN0148A Navigator keypad
74 GEN0156A GEN0156A Perimeter switch back cover
14 GEN0162A GEN0162A Snap lock (straight)
16 GEN0163A GEN0163A Snap lock (curved)
42 GEN0171A GEN0171A Motor shading
75 GEN0175A GEN0175A Stake for perimeter switch
51 GEN0176A GEN0176A Docking Board seal
18 GEN0182A GEN0182A Cover-base seal ring
39 GEN0201A GEN0201A Wheel Cup (black)
22 GEN0202A GEN0202A Ground clearance limiter
28 GEN0207A GEN0207A Front Wheel stopper
27 GEN0208A GEN0208A Front Wheel stopper spring
26 GEN0210A GEN0210A Charging socket rubber cover
87 GEN0211A GEN0211A Charging plug rubber cover
(2005)
Battery holder for perim.switch with screws
External charger cord - UK
External charger cord - US
External charger cord - EUR
Wire twist lock for bat. cable
-------- Plastic rivet (between cover and base)
--------- RL Operating & Safety CD (En)
Lamp Board
Rear Right Wire Sensor Board (old configuration)
Fuse AT blade 30A 32V
Fuse AT blade 1A 32V
Fuse mini blade 5A
Fuse 5x20 10A 125V (External Charger)
