Friendly Robotics robomower RL350 Service Manual page 6

1.1.2 Robomow bottom view
Note: Mower sides are determined by its top view
16
Snap lock (curved)
GEN0163A (x4)
15
High cut blades
MRK0002A
Low cut blades
MRK0003A
14
Snap lock (straight)
GEN0162A (x6)
10
Front Bumper
MSB0106B
Rear Bumper
MSB0107B
5
Figure 1.1.2 Bottom view
1
11
Front Wheel
SPP0011A
12
Mowing Motor
MSB0065B (x3)
3
Knobby drive wheel
MSB0099A
13
RL plastic base
GEN0095A
3
