4. Docking state.
If the charging is done through the charging socket (placed in the Manual Controller
Holder) then '00' is displayed in the docking state.
If the charging is done through the Docking Station, one of the following numbers is
displayed:
01 - Charging through the docking station
02 - Problem in charging through the docking station
03 - Robomow is trying to reconnect to the docking station for recharging
04 - Automatic departure time
05 - The user initiated the departure time
06 - Disconnected from charging in order to cool down because of overheat in the
ambience-charging temp.
07 - Disconnected from charging in order to cool down because of overheat in the
charging FET temp.
08 - Disconnected from charging in order to cool down because of overheat which is
caused when battery voltage is too high during charging.
09 - Disconnected from charging in order to heat up when needed
10- Disconnect from charging in order to perform the 'Learn entry points' sequence
11 - Disconnected from docking contacts
5. Charging time.
Indicates the charging time in hours from the time the Robomow is connected to the
Power Supply/Docking Station.
6. Charging FET d2a.
Indicates the charging FET state (for minimal charging voltage value is 250 – stage 4 in
the charging process, for maximal charging voltage value is 60 – stage 1 in the charging
process)
Definition: FET (Field-Effect Transistor) A transistor whose control, or gate, signal
creates an electro-magnetic field, which turns the transistor ON or OFF.
7. Charging FET temperature.
Indicates FET temperature (ºC) while in charging. If temperature > 125ºC then cooling is
required.
8. Ambience temperature.
Indicates the ambience temperature (ºC).
9. Charging enable flag.
Indicates if charging is enabled.
0 – Charging is disabled.
1 – Charging is enabled.
