Technical Service Bulletin
Date:
Product Model:
Two versions of the gear frame are found in the field. One version utilizes a ground clearance-
limiting riser molded as part of the frame, while the other does not.
SPP0004B and SPP0015A will have the riser removed when received as a spare part.
Included with these two parts is Ground Clearance Limiter part # GEN0202A. When using the
gear frame version with the riser removed on units with the larger knobby/treaded wheels, it is
also necessary to install the limiter (GEN0202A) to allow proper clearance between the wheels
and the cowling. See Figure below. When using the frame where the riser is intact on units with
knobby/treaded wheels, no additional procedure is required and the limiter (GEN0202A) is not
needed.
October 23, 2005
All
Gear Case/ Frame Modification
Service Bulletin #RL0536-02
Part Number:
Serial Range:
SPP0004B / SPP0015A
All
7
3
