Friendly Robotics robomower RL350 Service Manual page 55

5. Hardware over current.
Indicates if mow over current is detected by Hardware current limiter.
0 – Over current not detected.
1 - Over current detected
6. Mow temperature (ºC) or over current event counter
The display will switch every 3 seconds between:
1) Mow temperature in ºC.
2) Mow over current events counter.
If mowing motors are off the following information will be displayed:
1. '0' (A constant '0' will be displayed)
2. Should be '0', otherwise represents the mowing disable reason.
3. Operation state.
4. Last stop cause reason.
5. Current movement id.
6. Should be '0', otherwise represents the mowing disable reason.
6.3.11 Factory Defaults
Factory defaults will return all changeable settings back to the original factory setting. This can be
helpful if the user has changed many settings, as it is faster than changing each item
independently. After 'Factory defaults' is selected, the following procedures should be completed:
'Learn wire sensors', 'Edge Calibration', 'Set country' and 'DK Calibration'.
.
