Friendly Robotics robomower RL350 Service Manual page 57

Message Displayed
Drive Overload
Cooling, Wait...
Drive problem
Enter Code
Front/Rear bumper disc.
Front/Rear bumper pressed
Front Wheel Problem
High temp.
Disc. charger
High temp.
Waiting...
Keep charging if not used
Keys locked
Probable Cause/Event
- The drive motors have been working
under a severe load for too long.
- Internal failure
- The theft guard system is activated
- Internal bumper failure
- Front or Rear Bumper is constantly
being pressed
- The Front Wheel has left the ground for
more than 8 – 10 seconds.
- Robomow is charged through the plug
and ambience temperature is out of
range (above 158ºF / 70ºC)
- Robomow is charged through the
Docking Station and the ambience
temperature is out of range (above
158ºF / 70ºC);
- Message is displayed every time the
charger plug is disconnected from the
mower.
- Displayed when the mower isn't in
operation and not connected to the
charger/Docking for a long time.
- Child lock feature has been activated
Corrective/User Action
- There is no need to do anything – Robomow
will renew automatically the operation after the
drive motors will cool down to temperature
that allows operation.
- Contact service provider
- Enter the correct 4-digit code. 'Theft Guard'
can be deactivated under 'User Preferences'.
Contact your service provider for assistance in
a lost code situation.
- Contact service provider
- Move mower away from object pressing
against bumper.
CAUTION – Remove power pack before lifting
the mower
- The Robomow has driven onto an obstacle,
raising the front end. Remove or exclude this
object from the mowing area.
- The Robomow is being used on a slope too
steep for safe mowing. Exclude this from the
mowing area.
- High grass is preventing the front wheel from
fully riding on the ground. Raise the cutting
height.
- The ground contains large holes or indentions
where the front wheel can drop into when
passing across. Fill these areas with dirt and
level off.
- Robomow charging is not allowed when the
ambience temperature is raised above 158ºF /
70ºC; Disconnect the charger plug and wait
until the temperature will go down or take the
Robomow to be charged in a cooler place.
- Do not do anything, the charging is stopped
and Robomow is waiting for temperature to
change back to the allowed range; if
temperature stays out of the range for more
than 12 hours, the message is changed to
'High temp. Press GO'.
- Press any key to change the display back.
- Send the mower back to the Docking Station
for charging / connect the charging plug or
continue in operation
- Press the Up ⇑ arrow key and then press the
'C' button. Child lock can be deactivated
under User preferences.
