2.2 Menu Items Explanation
They following section explain the different menu items appeared in section 2.1 above:
1.0 User Preferences
1.1 Zones Setup
Allows user to set the parameters that are specific per zone
1.1.1 Work Time
Allows the user the option of setting the operating time from the 'MAX' default setting to
times ranging from 20 minutes up to 2:40 hours. This option is available for up to 4 different
zones, Dock Zone, Zone B, C or D. Having four different zones can allow you to set
operating time for several different zones that are of varying sizes, not requiring the same
operating time for mowing.
Note: for Dock zone it is possible to set different work time per operation when setting the
automatic weekly program.
1.1.2 Learn Edge
The default distance for edge mowing is approximately 1.5 to 2 rounds around the perimeter.
This feature allows the user to learn a specific distance in each operating zone in order to
cause the mower to cut the edge a specific distance, such as one full round. This can increase
the efficiency by minimizing the time spent on edge mowing. In some rare cases, because of
some unique geometry of the lawn, a mower may not complete edge under the normal default
operation. This feature allows you to overcome the issue by learning the edge in that zone. It
will remain as a learned distance until the edge is re-learned or the factory default edge is
selected.
1.1.3 Set Default Edge
Returns the edge mowing distance back to the factory default in the zone selected.
1.2 Sound
The sound feature allows the user to disable all audio effects except those related with safety.
1.3 Wire Position
Allows user to test the wire position in 'Edge' mode while the mowing motors are switched off to
prevent any damage to the perimeter wire after the initial setup of the wire is completed.
1.4 Language
Changes the LCD display on the Manual Controller to read in alternate languages.
1.5 Wide Scan
Wide scan is a second navigation method, where the angles between subsequent legs are
increased. This method should be selected in lawns where the mower appears to be driving back
and forth along the same path, not advancing to the left or right while mowing.
