Message Displayed
Low battery
Low temp.
Disc. charger
Low temp.
Waiting...
Left/Mid/Right mow problem
Move from Wire
Mowing Overload
Cooling, Wait
No Wire Signal
Rain detected
Go to ignore
(Enhanced Manual Controller
only)
Ready
Keep Charging
Recharge Battery
Replace blades
every 200 hours
Replace lamp
Retry elsewhere
Set Country
Set Time
Skipped: Low bat
Skipped: Rain
(Only Enhanced Manual
Controller)
Probable Cause/Event
- Mower is searching for the Docking
Station but the battery voltage is too
low to continue the searching process
- Robomow is charged through the plug
and ambience temperature is out of
range (below 32 ºF / 0 ºC); disconnect
the charger plug from the Robomow.
- Robomow is charged through the
Docking Station and the ambience
temperature is out of range (below
32ºF / 0ºC);
Mowing motor is faulty or disconnected
- The Robomow is positioned too close
or on top of the perimeter wire
- The mowing motors have been working
under a severe load for too long of a
time.
- Perimeter Switch is not turned on or
not connected to the zone intended to
mow
- Robomow detects rain upon GO
pressing
- The battery is fully charged
- The maximum operating time has been
reached
- An automatic reminder to replace the
blades is displayed every 200 hours
- The Operating Lamp is burnt out
- Calibration failure from interference in
the immediate area
- Displayed only on first use.
- Displayed every time the power pack is
taken out of the mower (reset
operation)
- Robomow has skipped the last depart
due to low battery voltage
- Robomow has skipped the last depart
due to rain detection
Corrective/User Action
- Drive the mower manually for charging in the
Docking Station
- Robomow charging is not allowed when the
ambience temperature is going down below
32ºF / 0ºC; Disconnect the charger plug and
wait until the temperature will go down or take
the Robomow to be charged in a warmer
place.
- Do not do anything, the charging is stopped
and Robomow is waiting for temperature to
change back to the allowed range; if
temperature stays out of the range for more
than 12 hours, the message is changed to
'Low temp. Press GO'.
Contact service provider
- Move the Robomow approximately 6 – 10 feet
(1.5 – 3m) away from the perimeter wire and
start again.
- There is no need to do anything – Robomow
will renew automatically the operation after the
mowing motors will cool down to temperature
that allows operation.
- Make sure the Perimeter Switch is connected
to the correct zone and is turned on
- Do not operate Robomow in rainy weather
and wet grass; If you choose to override,
press the GO button; The overriding is valid
for the current operation only
- Keep the charger (power supply) connected
and operating
- Connect the charger to the mower
- Replace the blades and restart the counter of
the blades replacement reminder by choosing
the 'Blades replaced – Clear reminder'
option under the 'User Preferences' menu
- Confirm the message and replace the
Operating Bulb as soon as possible
- Move the Robomow 10-12 feet (3-4m) from
this spot and attempt calibration again.
- Follow prompts on LCD screen to set country
- Set real time clock (day and hour)
- Confirm there is enough time between the two
adjacent departures so the battery can be
charged prior the scheduled operation (min 16
hours between operations)
- It is not recommended to cut wet or damp
grass, but if you choose to override the rain
sensor, change the setting of the 'Rain sensor'
to 'off' under the 'User preferences' menu.
