5.5.10.5 Drive motors

In this display the LCD will display the following information:
1.Left drive current (A2D) 1.Left drive current (A2D) 1.Left drive current (A2D)
4.Over current counter 4.Over current counter 4.Over current counter
1. Left drive current.
Left drive current in a2d.
2. Right drive current.
Right drive current in a2d.
3. Right drive temperature (ºC).
Right drive temperature in ºC.
4. Over current counter.
Indicates if drive over current is detected either by Hardware current limiter or by
Software current readings.
0 – No over current
Otherwise - over current.
5. Hardware over current.
Indicates if drive over current is detected by Hardware current limiter.
0 – Over current not detected.
1 - Over current detected
6. Right drive temperature (a2d).
Right drive temperature in a2d.

5.5.10.6 Mow motors

In this display the LCD will display the following information:
1.Left mow current (A2D) 1.Left mow current (A2D) 1.Left mow current (A2D)
4.Over current counter 4.Over current counter 4.Over current counter
1. Left mow current.
Left mow current in a2d.
2. Middle mow current.
Middle mow current in a2d.
3. Right mow current.
Right mow current in a2d.
4. Over current counter.
Indicates if mow over current is detected either by Hardware current limiter or by
Software current readings.
0 – No over current
Otherwise - over current
2.Right drive current (A2D) 2.Right drive current (A2D) 2.Right drive current (A2D)
5.Hardware over current 5.Hardware over current 5.Hardware over current
2.Middle mow current (A2D) 2.Middle mow current (A2D) 2.Middle mow current (A2D)
5.Hardware over current 5.Hardware over current 5.Hardware over current
3.Right drive temperature (ºC) 3.Right drive temperature (ºC) 3.Right drive temperature (ºC)
6.Right drive temperature (A2D) 6.Right drive temperature (A2D) 6.Right drive temperature (A2D)
3.Right mow current (A2D) 3.Right mow current (A2D) 3.Right mow current (A2D)
6.Temperature (ºC). or over current event counter 6.Temperature (ºC). or over current event counter 6.Temperature (ºC). or over current event counter
