1.3 External View and Parts Names

EXTERNAL VIEW
Stylus Pro 4400/4800
Paper Cover Printer Cover
Ink Cartridge Box
(Left side)
NOTE: 4-color model is equipped with a cover instead of the ink cartridge box (right).
Product Description
Spindle Paper Set Lever Control Panel
Ink Cartridge Box
(Right side)
ASF Cassette Maintenance Tank
Figure 1-5. External View and Parts Names (Stylus Pro 4400/4800)
External View and Parts Names
Type-B Interface
IEEE1394 Interface USB Interface
Revision C
Paper Guide Center Unit
(Rear cover)
AC Inlet
