EPSON Stylus Pro 4400/4450/4800/4880/4880C
Switch
Pause
+
Select paper type / Paper Cut [<]
Select paper type / Paper Cut [<]
+
Paper Feed / Eject Paper [∧]
+
Paper Feed / Eject Paper [∨]
Select paper type / Paper Cut [<]
+
Paper Feed / Eject Paper [∧]
+
Paper Feed / Eject Paper [∨]
+
Menu / Cleaning [>/↵]
Note *1: Power OFF must be executed regardless of printer status.
*2: Following are the conditions for cleaning.
• Idling (In on-line: Inside the panel menu is not in on-line.)
• Printing
*3: LCD panel display only changes when key is not pressed during the shift from idling status to printer setting menu. Other than this, switch over of display is executed when
the key is pushed.
*4: When key is not pressed, LCD icon for paper type is switched over.
*5: During ink drying, ink drying is interrupted and runs the specified operation.
*6: 5cps paper feeding for 2 seconds after the button is pressed. 52cps paper feed if pressed for a further 2 seconds. Maximum reverse feeding is 37cm with one press of the
button.
*7: 5cps paper feeding for 2 seconds after the button is pressed. 52cps paper feed if pressed for a further 2 seconds.
*8: Can be switched when roll paper remaining detection is on or cut sheet remaining detection is on in Maintenance Mode 2. While the detection is stopped, the printer stops
the counter operation and blinks the counter value.
Product Description
Table 1-23. Panel Functions and Switch Operation
Single
Switches Stop ↔ Operation of remaining
*8
paper detection during standby
Function
3 sec. push
Operating Panel
Revision C
Function Function
(In panel setting) (+ Power ON)
Maintenance mode 2
F/W download
