CVM-C10
4.9.- PROGRAMMING
From the programming menu you can:
 Lock the status of the menu.
 Define the transformation ratios.
 Select the number of quadrants and type of installation.
 Select the operation profile of the device.
 Program the carbon emission ratio, kgCO
 Program the cost ratio.
 Program the maximum demand parameters.
 Delete the energy meters and the maximum and minimum values.
 Modify the display's backlight.
 Activate the harmonic display option.
 Program alarms.
 Program Modbus communications
The programming parameters are validated as follows:
 When on reaching the last point on the programming menu ("
") the key is pressed
gramming
 At any point in the programming, by pressing the key
conds.
If the device is RESET before validation or no key is pressed for 30 seconds, the configuration
will not be stored in the memory.
To enter the programming menu press the
The home screen of the menu indicates whether the menu is locked or not:
Press key to access the first programming step.
The following screen will be displayed if the programming menu is locked,
Instruction Manual
key for 3 seconds.
UnLOC
When you enter the programming menu you can view and modify
the programming. Icon
is not locked.
LOC
When you enter the programming you can view the programming
but not modify it. Icon
.
2,
4.9.30. Locking the pro-
or
on the display indicates that the unit
indicates the locking status.
pressing for 3 se-
LOC
:
45
