The variable format is shown in
4�10�3�7�15� Digital outputs
Reading the status of the digital outputs.
The 0x04 function is implemented for this variable.
Status of the digital outputs
Status of the digital outputs
The variable format is shown in
4�10�3�7�16� Communications
Protocol
Modbus and BACnet: Peripheral number
Modbus : Transmission speed
Modbus : Parity
Modbus : Data bits
Modbus : Stop bits
BACnet: Device ID
BAcnet: MAC
4.10.3.7.17. Password configuration
These variables allow you to lock or unlock access to the programming menu, and also allow
you to change the password code. The password code may only be changed through this com-
mand.
The device does not need you to enter the old password in order for it to record the new one; it
records the new one directly without any verification.
