CVM-C10
In addition, there are some parameters (
time (OR function). If you have selected one of these variables, the alarm will be activated when
any of the three phases meets the programmed conditions.
 Programming the maximum value
When the desired value is shown on the screen, move onto the next digit by pressing the key
to modify the other values.
In the case of some parameters (
To do so, press key
Press key repeatedly to modify the position of the decimal point.
When the decimal point is in the desired position, press the key
pressing now the key
Note: Pay special attention when programming the Generation Power (displayed with negative
values).
Example: If you wish to enter a generation power alarm with limits between 2 kW and 1 kW,
program the following as the maximum value : - 1 kW and the following as the minimum
value : - 2 kW.
To validate the data, press
Press key to access the next programming step
Instruction Manual
Table 17
Table 17:Multiple parameter codes for alarm programming�
Types of parameters
Phase-Neutral Voltage
Current
Active power
Inductive Reactive Power
Capacitive Reactive Power
Power factor
Phase-Phase Voltage
% THD V
% THD A
Apparent Power
The maximum value: the alarm is activated when this value is
exceeded.
Press key for 3 seconds to edit the maximum value selection.
The prog icon will be displayed on the bottom of the screen.
To enter or modify the value, press the
increasing the value of the flashing digit.
), you can modify the position of the decimal point.
Table 18
after modifying the last digit and the decimal point will start flashing.
we can set a positive or negative value.
for 3 seconds and the prog icon will disappear from the display.
) that refer to the three phases at the same
Code
200
201
202
203
204
205
206
207
208
209
to end the programming,
key repeatedly,
