CVM-C10
The installation's consumed and generated energy are displayed on the e
The installation status is also displayed:
Installation is consuming energy.
Installation is generating energy.
A long keystroke (3 sec) of key
The generation values are identified with the negative sign on the screen, which appears in
front of each parameter.
A long keystroke (3 sec) of key
Use keys and
Screen
Instruction Manual
will display the generation values.
will display the consumption values.
to browse the different screens (short keystroke).
Table 14: Screens of the e
Inductive Reactive Energy Tariff 1, T1 (M/Kvar
Inductive Reactive Energy Tariff 2, T2 (M/Kvar
Inductive Reactive Energy Tariff 3, T3 (M/Kvar
Total Inductive Reactive Energy (M/Kvar
profile.
3
Parameters (units)
Active Energy Tariff 1 , T1 (M/KWh)
Active Energy Tariff 2 , T2 (M/KWh)
Active Energy Tariff 3 , T3 (M/KWh)
Total Active Energy (M/KWh)
Consumption and generation values
Only available for the 4 quadrant option.
Apparent Energy Tariff 1, T1 (M/KVAh)
Apparent Energy Tariff 2, T2 (M/KVAh)
Apparent Energy Tariff 3, T3 (M/KVAh)
Total Apparent Energy (M/KVAh)
Consumption and generation values
Only available for the 4 quadrant option.
Consumption and generation values
Only available for the 4 quadrant option.
profile of the device.
3
h)
L
h)
L
h)
L
h)
L
