4�9�23� PROgRAMMINg ALARM 1 (ReLAy 1)
Note : Configuration parameters not available for the CVM-C10-FLEX model.
To enter or modify the value, press the
digit.
When the desired value is shown on the screen, move onto the next digit by pressing the key
to modify the other values.
When you enter the code of a variable on the display, the symbols for that variable will be
activated.
Set the value to 00 if you do not wish to program a variable.
If you press the
can modify the previously programmed values again.
To validate the data, press
Press key
Parameter
Phase-Neutral Voltage
Current
Active power
Inductive Reactive Power
Capacitive Reactive Power
Apparent power
Power factor
Cosine φ
% THD V
% THD A
Phase-Phase Voltage
Frequency
Neutral current
Maximum current demand
Active Power Maximum
Demand
Apparent Power Maximum
Demand
58
The variable code is selected on this screen, depending on
which will control alarm relay 1.
16,
Press key
icon will be displayed on the bottom of the screen.
key after changing the last digit, it will jump back to the first digit so you
for 3 seconds and the prog icon will disappear from the display.
to access the next programming step.
Table 16: Parameter codes used to program the outputs�
Phase
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1
L1/2
-
-
L1
-
-
for 3 seconds to edit the code selection. The prog
key repeatedly, increasing the value of the flashing
Code Phase Code
01 L2 09
02 L2 10
03 L2 11
04 L2 12
05 L2 13
06 L2 14
07 L2 15
08 L2 16
36 L2 37
39 L2 40
32 L2/3 33
31 - -
35 - -
45 L2 46
- - -
- - -
Phase Code Phase Code
L3 17 -
L3 18 -
L3 19 III
L3 20 III
L3 21 III
L3 22 III
L3 23 III
L3 24 III
L3 38 -
L3 41 -
L3/1 34 -
- - -
- - -
L3 47 III
- - III
- - III
