Page 1 DocuPrint 2050 Service Manual 1st Edition ON001CA...
Page 2 Handle with care to avoid loss or damage of • This service manual covers the following the manual. models FUJI XEROX Co. Ltd. Color Laser Printer • Revision and Modification Information DocuPrint 2050 When design changes or revisions relating to this service manual occur, the overseas •...
Page 3 Company Name Department Name Telephone No. Full Name Employee No.
Page 4 Introduction Getting to know the Service Manual How to use the Service Manual Terms and Symbols Abbreviations Chapter 1 Service Call Procedure Chapter 2 Troubleshooting Chapter 3 Image Quality Troubleshooting Chapter 4 Disassembly/Assembly and Adjustment Chapter 5 Parts List Chapter 6 General Chapter 7 Wiring Data Chapter 8 Accessories Not issued...
Page 5 Preface...
Page 6: Table Of Contents
Preface Table of Contents Table of Contents 1. Getting to know the Service Manual..............Preface - 2 2. How to use the Service Manual................ Preface - 2 2.1 Contents of Manual.........................Preface - 2 2.2 Information on Updating......................Preface - 3 3. Terms and Symbols..................Preface - 4 4.
Page 7: Getting To Know The Service Manual
2. How to use the Service Manual This manual describes the standard procedures for the servicing of the DocuPrint 2050. Refer to Chapter 1 Service Call Procedure for efficient and effective servicing during maintenance calls. 2.1 Contents of Manual •...
Page 8: Information On Updating
Chapter 9 BSD (Block Schematic Diagram) (Not issued) Chapter 10 Machine Overview This chapter gives an overview of the functions of the main components of DocuPrint 2050. 2.2 Information on Updating This manual will be revised and sent to each customer engineer as specified below. Revisions must be incorporated correctly to keep the manual up-to-date.
Page 9: Terms And Symbols
Indicates the parts list for reference. • ASSY Means Assembly. Safety Critical Components (SCC) For the safety control of the Safety Critical Components and the components specified, follow the regulations regarding the Safety Critical Components set by Fuji Xerox Co., Ltd. Preface-4...
Page 10: Abbreviations
Introduction 4. Abbreviations 4. Abbreviations Abbreviations This manual contains abbreviations that are specific to this manual, as well as general abbreviations, which include: ASSY Assembly LVPS Low Voltage Power Supply AUX. Auxiliary Machine(Main) Control Unit Bias Charge Roll MOT. Motor Bias Transfer Roll Multi Purpose Clutch...
Page 11 Chapter 1 Service Call Procedure...
Page 12 Chapter 1 Service Call Procedure Table of Contents Table of Contents 1.1 Before Starting the Servicing..................1 - 2 1.1.1 Safety............................. 1 - 2 1.1.2 Other Things to Note........................1 - 3 1.2 Servicing Call Procedure ...................1 - 4 1.3 TRIM Servicing ......................1 - 5 1.3.1 TRIM Servicing Procedure......................
Page 13: Before Starting The Servicing
Chapter 1 Service Call Procedure 1.1 Before Starting the Servicing 1.1 Before Starting the Servicing 1.1.1 Safety To prevent any accident that may occur during maintenance servicing, any WARNING or CAUTION regarding the servicing must be strictly observed. Do not perform any hazardous operation. 1.
Page 14: Other Things To Note
Record the service details and the consumables and parts replaced at visit in the Machine Service Log. DocuPrint 2050 weighs 14.8kg. Always have 2 or more people available to move the printer. Refer to the Installation Procedures for details.
Page 15: Servicing Call Procedure
Chapter 1 Service Call Procedure 1.2 Servicing Call Procedure 1.2 Servicing Call Procedure 1. Ask the operator(s) about the machine condition. 2. Record the billing meter readings. Initial Actions 3. Inspect any printing error, then check the machine. 4. Check the Service Log. 1.
Page 16: Trim Servicing
Chapter 1 Service Call Procedure 1.3 TRIM Servicing 1.3 TRIM Servicing TRIM Servicing for DocuPrint 2050 is performed in all SM/UM to maintain the performance of the machine. Independent visits for TRIM Servicing does not take place. 1.3.1 TRIM Servicing Procedure 1.
Page 17: Machine Consumables And Periodic Replacement Parts
Chapter 1 Service Call Procedure 1.3 TRIM Servicing 1.3.2 Machine Consumables and Periodic Replacement Parts Check the total number of copies printed during TRIM Servicing before replacing the machine consumables. Machine Consumables Consumables Product Code Life Drum/toner cartridge CWAA0666 10KPV Periodic Replacement Parts Consumables Replacement Interval...
Page 18: Trim Check List
Chapter 1 Service Call Procedure 1.3 TRIM Servicing 1.3.3 TRIM Check List A --- Perform checking. Clean, replace, or supply if necessary. B --- Always perform cleaning and checking. C --- Always perform replacement service at the specified interval. * Refer to pages 3-13 on how to print test patterns. Disassembly/ Every Servicing Items...
Page 19 Chapter 2 Troubleshooting...
Page 20 Chapter 2 Troubleshooting Table of Contents Table of Contents 2.1 Advancing Troubleshooting ..................2 - 3 2.1.1 Troubleshooting Flow........................2 - 3 2.1.2 Precheck ............................2 - 4 2.1.3 Notes on Work ..........................2 - 4 2.1.4 Notes on Using FIP........................2 - 5 2.2 Level 1 FIP ........................2 - 6 2.2.1 Level 1 FIP.............................
Page 21 Chapter 2 Troubleshooting Table of Contents 2.4.1.2 Connection........................... 2 - 38 2.4.1.3 Activating ..........................2 - 38 2.4.1.4 Operation Modes ......................... 2 - 39 2.4.1.5 Activation Screen ......................... 2 - 40 2.4.1.6 Install instructions for Diagnostic Interface ................2 - 42 2.4.1.7 Main Menu ...........................
Page 22: Advancing Troubleshooting
Chapter 2 Troubleshooting 2.1 Advancing Troubleshooting This chapter describes the Fuji Xerox Printing Systems standard specifications and NOTE cases where the printer controller is normal. When the printer controller directly controls the device or the unique specifications of the OEM destination is provided, troubleshooting varies depending on the specifications of the OEM destination.
Page 23: Precheck
Chapter 2 Troubleshooting 2.1 Advancing Troubleshooting 2.1.2 Precheck Be sure to check the following items before beginning the troubleshooting. The power voltage is within the specifications. (Measure the voltage at an outlet.) There is no damage, short, cut-off, or connection error in the cable AC. Exactly ground the device.
Page 24: Notes On Using Fip
Chapter 2 Troubleshooting 2.1 Advancing Troubleshooting 2.1.4 Notes on Using FIP 1) If troubleshooting is still impossible, replace the major check parts listed at initial check and related parts in sequence. 2) When using the FIP for troubleshooting, a normal PWBA MCU XFABK(B) and Drum/toner cartridge may be required to isolate a fault.
Page 25: Level 1 Fip
Chapter 2 Troubleshooting 2.2 Level 1 FIP 2.2 Level 1 FIP 2.2.1 Level 1 FIP The level 1 FIP is the first step for trouble diagnosis. The level 1 FIP isolates the presence of various troubles including error codes, and the level 2 FIP provides a guide for proceeding of the troubleshooting.
Page 26: Level 2 Fip
Chapter 2 Troubleshooting 2.3 Level 2 FIP 2.3 Level 2 FIP 2.3.1 Level 2 FIP The Level 2 FIP is the trouble diagnostic procedure to sort various troubles in addition to the error codes. In the troubleshooting, executing the steps given in the FIP or checking procedure allows you to find out a cause of trouble in a short time.
Page 27: Errors And Statuses
Chapter 2 Troubleshooting 2.3 Level 2 FIP Printer LED Simple Monitor Message (BLK=Blink) Error Status Green Printing Status Window Window Jam within Printer Paper jammed at the main FIP- Paper Jam assembly 1.6/1.7 Jam in Paper Supply Paper jammed at the paper- FIP- Paper Jam Section...
Page 28 Chapter 2 Troubleshooting 2.3 Level 2 FIP Error status Contents or detection conditions Clear method Cover open The cover is opened. Close the Front or Top - The Front or Top Cover is opened. Cover. Fuser alarm Temperature error in fusing unit Turn the power on and off.
Page 29: Error Code Fip
Chapter 2 Troubleshooting 2.3 Level 2 FIP 2.3.4 Error Code FIP FIP-1.1 Drum/toner cartridge (No cartridge, Cartridge error) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, - There is a tool. transformation, dirt, or foreign object? Replace and To step 2...
Page 30: Fip-1.2 Paper Size Unmatching (Paper Size Error)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.2 Paper size unmatching (Paper size error) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? - Major check parts - Replace and To step 2...
Page 31: Fip-1.3 No Paper (Paper Empty)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.3 No paper (Paper empty) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? Replace and To step 2 - Major check parts - reattach the parts.
Page 32: Fip-1.4 Mis Feed Jam (Jam Or Pick Error)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.4 MIS FEED JAM (Jam or pick error) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? - Major check parts - PLATE ASSY GEAR (PL5.1.26/PL7.1.3), ROLL ASSY FEED REAR (PL5.1.36), ROLL FEED FRONT D...
Page 33 Chapter 2 Troubleshooting 2.3 Level 2 FIP <Continued from the preceding page> Action Procedure Check - ACTUATOR ASSY REGI check - - There is a tool. Does the ACTUATOR ASSY REGI run smoothly? To step 10 Replace the - There is no tool. ACTUATOR Go to FIP-2.4, ASSY REGI...
Page 34: Fip-1.5 Too Quick Jam (Jam Or Pick Error)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.5 Too quick jam (jam or pick error) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? - Major check parts - Replace and GEAR ASSY (PL7.1.1), ROLL ASSY FEED REAR...
Page 35: Fip-1.6 Regi. Jam (Jam Or Pick Error)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.6 REGI. JAM (Jam or pick error) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? - Major check parts - FUSER ASSY CL CH (PL7.1.15), SENSOR EXIT Replace and...
Page 36 Chapter 2 Troubleshooting 2.3 Level 2 FIP <Continued from the preceding page> Action Procedure Check - PLATE DT SAW check - Replace/Clean Is the PLATE DT SAW dirty, dusty, or transformed? the PLATE DT To step 10 - HEAT ROLL/PRESSURE ROLL rotation check - Replace the Does the HEAT ROLL or PRESSURE ROLL of the To step 11...
Page 37: Fip-1.7 Exit Jam (Jam Or Pick Error)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.7 Exit jam (Jam or pick error) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? - Major check parts - Replace and To step 2...
Page 38: Fip-1.8 Cover Top Cl Open (Cover Open)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.8 COVER TOP CL open (Cover open) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? Replace and - Major check parts - To step 2...
Page 39: Fip-1.9 Cover Assy Front Open (Cover Open)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.9 COVER ASSY FRONT open (Cover open) Action Procure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? Replace and - Major check parts - To step 2...
Page 40: Fip-1.10 Fuser Error (Fuser Alarm)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.10 Fuser error (Fuser alarm) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? Replace and To step 2 - Major check parts - reattach the parts.
Page 41: Fip-1.11 Ros Error (Ros Or Scanner Motor Alarm)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.11 ROS error (ROS or scanner motor alarm) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, - There is a tool. transformation, dirt, or foreign object? Replace and To step 2...
Page 42: Fip-1.12 Fan Error (Fan Alarm)
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.12 Fan error (Fan alarm) Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and transformation, dirt, or foreign object? To step 2 reattach the parts.
Page 43: Fip-1.13 Motor Assy Main Alarm
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.13 MOTOR ASSY MAIN alarm Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? - There is a tool. - Major check parts - Replace and To step 2...
Page 44: Fip-1.14 Bd Alarm
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.14 BD alarm Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and transformation, dirt, or foreign object? To step 2 reattach the parts.
Page 45: Fip-1.15 Printing Error
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-1.15 Printing error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and transformation, dirt, or foreign object? To step 2 reattach the parts.
Page 46: Other Fip
Chapter 2 Troubleshooting 2.3 Level 2 FIP 2.3.5 Other FIP FIP-2.1 LVPS 230 error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and To step 2 transformation, dirt, or foreign object? reattach the parts.
Page 47: Fip-2.2 Ros Assy Error
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-2.2 ROS ASSY error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and transformation, dirt, or foreign object? To step 2 reattach the parts.
Page 48: Fip-2.3 Switch P/Size Error
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-2.3 SWITCH P/SIZE error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? Replace and To step 2 - Major check parts - reattach the parts.
Page 49: Fip-2.4 Pwba Sensor Error
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-2.4 PWBA SENSOR error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and transformation, dirt, or foreign object? To step 2 reattach the parts.
Page 50: Fip-2.5 Sensor Exit Error
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-2.5 Sensor Exit error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? - Major check parts - Replace and To step 2 SENSOR EXIT (mounted on the FUSER ASSY CL CH),...
Page 51: Fip-2.6 Clutch Regi Roll A Error
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-2.6 CLUTCH REGI ROLL A error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and transformation, dirt, or foreign object? To step 2 reattach the parts.
Page 52: Fip-2.7 Gear Assy Error
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-2.7 GEAR ASSY error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and transformation, dirt, or foreign object? To step 2 reattach the parts.
Page 53: Fip-2.8 Azusa Hvps Error
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-2.8 AZUSA HVPS error Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, Replace and transformation, dirt, or foreign object? To step 2 reattach the parts.
Page 54: Fip-2.9 Noise
Chapter 2 Troubleshooting 2.3 Level 2 FIP FIP-2.9 Noise Action Procedure Check - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt, or foreign object? Replace and - Major check parts - To step 2 reattach the parts.
Page 55: Preventive Maintenance
Chapter 2 Troubleshooting 2.3 Level 2 FIP 2.3.6 Preventive Maintenance Perform the preventive maintenance to prevent faults from being caused when visiting a customer. - Preventive maintenance procedure Ask the customer for the use status of the device. Record the accumulated number of printed papers. Determine whether the periodically-replaced parts are to be replaced with the NOTE number of printed papers.
Page 56: How To Use Pc Diag
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4 How to use PC Diag. This manual describes the Fuji Xerox Printing Systems standard specifications. NOTE When the printer controller directly controls the indicators (two LED lamps) or the OEM destination provides the unique specifications, refer to the relevant OEM specifications.
Page 57: Connection
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.2 Connection 1) Remove the COVER ASSY STACK. (See REP 1.7) 2) Remove the COVER ASSY CONTROLLER. (See REP 9.5) 3) Disconnect the PWBA MCU-sided connector of the flat cable connected to the PWBA MCU XFABK(B) and ESS PWB.
Page 58: Operation Modes
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.4 Operation Modes The Diagnostic And Software has the following three operation modes: - Test Pattern Mode:Test print processing - Diagnostic Mode:Part function check processing - LPT Port Setting Mode:LPT port selection processing To specify these modes, use the Main Menu.
Page 59: Activation Screen
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.5 Activation Screen When the Diagnostic And Software program is activated, the screen below appears. Wait until the device power is turned on. CAUTION If the screen does not change at power-on, the loose connection, contact error or installed by the privilege of Non-Administrators (in case of Windows2000 or XP) is thought.
Page 60: Install Instructions For Diagnostic Interface
Chapter 2 Troubleshooting 2.4 How to use PC Diag. Select each item. - Proceed to the Main Menu - Install instructions for Diagnostic Interface Use the up arrow and down arrow keys to select a desired item and press the [Enter] key. The selected item is highlighted.
Page 61: Main Menu
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.6 Install instructions for Diagnostic Interface It describes the procedure of connecting the PC and the device. Confirm the items, press the [Esc]. The [Main Menu] is displayed. 2.4.1.7 Main Menu Select each item on the Main Menu.
Page 62: Test Pattern Mode Menu
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.8 TEST PATTERN MODE MENU 2.4.1.8.1 Functions The Test Pattern Mode is used to print out the test patterns built in the device for operation check. The test printing self patterns are as follows: Number of horizontal solid lines...
Page 63: Entering Test Pattern Mode Menu
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.8.2 Entering TEST PATTERN MODE MENU Select [Test Pattern Mode] on the Main Menu. Press the [Page Down] key or the [Enter] key to go to the next page. The [TEST PATTERN MODE] screen is displayed. The feeder for test printing is displayed.
Page 64 Chapter 2 Troubleshooting 2.4 How to use PC Diag. The paper size appears under the Feeder field. (“B”) “A” “B” When the paper is not set, the [NO PAPER] is displayed. Then press the [Enter] key; printing starts. Warning! Confirm that the covers are attached normally at printing. Then check whether paper is supplied from a Paper Feeder and feed paper from a Feeder having papers.
Page 65: Diagnostic Mode Menu
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9 DIAGNOSTIC MODE MENU 2.4.1.9.1 Functions The Diagnostic Mode Menu displays the sensor and switch functions, component operations and functions, and ROM checksum value. 2.4.1.9.2 Diagnostic Code List Diagnostic Operation to be executed code Stop of all diagnostic operation or stop of self-test continuance printing...
Page 66: Entering Diagnostic Mode Menu
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.3 Entering DIAGNOSTIC MODE MENU Select [Diagnostic Mode] on the Main Menu and press the [Page Down] key or [Enter] key; the operation selection screen appears. Use the up arrow, down arrow, left arrow, and right arrow keys to select a desired item and press the [Enter] key.
Page 67: Stop All Test (Diagnostic Code 00)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.4 STOP ALL TEST (Diagnostic Code 00) This function stops all the diagnostic operations. This test stops diagnostic operations even when the screen returns to the Main NOTE Menu after the Diagnostic Mode ends. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Stop All Tests] from DIAGNOSTIC MODE MENU.
Page 68: Sensor/Switch Check (Diagnostic Code 01)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.5 SENSOR/SWITCH CHECK (Diagnostic Code 01) This function displays the reaction for each sensor provided in the device. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Sensor/Switch Check] from DIAGNOSTIC MODE MENU.
Page 69: Fuser Temperature Check (Diagnostic Codes 03 And 04)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.6 FUSER TEMPERATURE CHECK (Diagnostic Codes 03 and 04) This function displays the current fuser temperature. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Fuser Temperature Check] from DIAGNOSTIC MODE MENU.
Page 70: Rom Miner Version Check (Diagnostic Codes 06 And 07)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.7 ROM MINER VERSION CHECK (Diagnostic Codes 06 and 07) This function displays the version of the firmware. Use the up arrow, down arrow, left arrow, and right arrow keys to select [ROM Miner Version Check].
Page 71: Main Motor Test (Diagnostic Codes 0C)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.8 MAIN MOTOR TEST (Diagnostic Codes 0C) This function runs the main motor. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Main Motor Test] and press the [Enter] key;...
Page 72: Paper Feeder Pick Test (Diagnostic Code 0F)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.9 PAPER FEEDER PICK TEST (Diagnostic Code 0F) This function checks Pick Motor operation for PAPER FEEDER. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Paper Feeder Pick Test] and press the [Enter] key;...
Page 73: Msi Clutch Test (Diagnostic Code 0E)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.10 MSI CLUTCH TEST (Diagnostic Code 0E) This function checks Clutch operation for MSI feeding. Use the up arrow, down arrow, left arrow, and right arrow keys to select [MSI Clutch Test] and press the [Enter] key;...
Page 74: Regi. Roll Clutch Test (Diagnostic Code 14)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.11 REGI. ROLL CLUTCH TEST (Diagnostic Code 14) This function checks clutch operation for REGI. Roll. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Regi Roll Clutch Test] and press the [Enter] key;...
Page 75: Single Self Print Test (Diagnostic Code 15)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.12 SINGLE SELF PRINT TEST (Diagnostic Code 15) This function prints one test pattern built in the device for operation check. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Single Self Print Test] and press the [Enter] key;...
Page 76: Charge Roll Ac Test (Diagnostic Code 17)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.13 CHARGE ROLL AC TEST (Diagnostic Code 17) This function applies AC voltage to the Charge Roll. WARNING Take great care that you do not receive an electric shock because the AC voltage is high.
Page 77: Charge Roll Dc Test (Diagnostic Code 18)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.14 CHARGE ROLL DC TEST (Diagnostic Code 18) This function applies DC voltage to the Charge Roll. WARNING Take great care that you do not receive an electric shock because the DC voltage is high.
Page 78: Developer Bias Ac Test (Diagnostic Code 19)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.15 DEVELOPER BIAS AC TEST (Diagnostic Code 19) This function applies AC voltage to the magnet roll as Developer Bias. WARNING Take great care that you do not receive an electric shock because the AC voltage is high.
Page 79: Developer Bias Dc Test (Diagnostic Code 1A)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.16 DEVELOPER BIAS DC TEST (Diagnostic Code 1A) This function applies DC voltage to the magnet roll as Developer Bias. WARNING Take great care that you do not receive an electric shock because the DC voltage is high.
Page 80: Transfer Roll-Test (Diagnostic Code 1B)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.17 TRANSFER ROLL-TEST (Diagnostic Code 1B) This function applies minus voltage to the Transfer Roll. WARNING Take great care that you do not receive an electric shock because the minus voltage is high. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Transfer Roll - Test] and press the [Enter] key;...
Page 81: Transfer Roll+Test (Diagnostic Code 1C)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.18 TRANSFER ROLL+TEST (Diagnostic Code 1C) This function applies plus voltage to the Transfer Roll. WARNING Take great care that you do not receive an electric shock because the plus voltage is high. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Transfer Roll + Test] and press the [Enter] key;...
Page 82: Fan Motor, High Speed Test (Diagnostic Code 1E)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.19 FAN MOTOR, HIGH SPEED TEST (Diagnostic Code 1E) This function rotates the Fan Motor at high speed. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Fan Motor, High Speed Test] and press the [Enter] key;...
Page 83: Fan Motor, Stop Test (Diagnostic Code 1F)
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.9.20 FAN MOTOR, STOP TEST (Diagnostic Code 1F) This function stops the Fan Motor. Use the up arrow, down arrow, left arrow, and right arrow keys to select [Fan Motor, Stop Test] and press the [Enter] key;...
Page 84: Lpt Port Setting Menu
Chapter 2 Troubleshooting 2.4 How to use PC Diag. 2.4.1.10 LPT PORT SETTING Menu 2.4.1.10.1 Functions The LPT Port Setting Menu is used to specify an LPT port address. The LPT port address varies depending on the PC used. Refer to the instruction NOTE manual of the model used or switch the LPT port to try this processing until the selected address matches the model used.
Page 85 Chapter 3 Image Quality Troubleshooting...
Page 86 Chapter 3 Image Quality Troubleshooting Table of Contents Table of Contents 3.1 Image Troubleshooting....................3 - 2 3.2 Image Quality Specifications ..................3 - 5 3.2.1 Print Guaranteed Area ........................3 - 5 3.3 Print Alignment ......................3 - 6 3.3.1 Lead edge registration ........................3 - 6 3.3.2 Side edge registration ........................
Page 87: Image Troubleshooting
Chapter 3 Image Quality Troubleshooting 3.1 Image Troubleshooting Troubleshooting in this manual assumes use of Diag. tools (maintenance tools). NOTE However, the troubleshooting allows for the case where the Diag tools are not used. You can correct troubles according to these troubleshooting procedures after understanding them well.
Page 88 Chapter 3 Image Quality Troubleshooting 3.1 Image Troubleshooting Description below assumes that the printer controller is normal. By testing the NOTE printing operation for the engine only, conditions can be isolated simply to determine whether the trouble exists on the printer controller side or engine side. - When the test print with the engine only is correct, the printer controller is fault.
Page 89 Chapter 3 Image Quality Troubleshooting 3.1 Image Troubleshooting The checkpoints against printing errors are as follows. NOTE Order Phenomenon Checkpoint Vertical thin part, white streak Drum/toner cartridge life, uneven toner Vertical stripe, partial thinness Dirty discharge conductor (PLATE DT SAW) Cyclic dot-like or island-like Approx.95mm OPC Drum damage...
Page 90: Image Quality Specifications
Chapter 3 Image Quality Troubleshooting 3.2 Image Quality Specifications 3.2 Image Quality Specifications 3.2.1 Print Guaranteed Area Guaranteed Guaranteed 420mm 420mm printing area printing area 410mm 410mm 287mm 287mm 297mm 297mm SI run 250-sheet tray run ON302CA...
Page 91: Print Alignment
Chapter 3 Image Quality Troubleshooting 3.3 Print Alignment 3.3 Print Alignment 3.3.1 Lead edge registration Measure how the print-out on paper is dislocated from the reference position. Measure how the reference position is dislocated 15mm from the paper edge in the center.
Page 92: Side Edge Registration
Chapter 3 Image Quality Troubleshooting 3.3 Print Alignment 3.3.2 Side edge registration Measure how the reference position is dislocated 148.5mm from the paper left end in the center.
Page 93: Skew
Chapter 3 Image Quality Troubleshooting 3.3 Print Alignment 3.3.3 Skew Measure the oblique paper feeding. Measure in the 245mm range on the horizontal line at the end.
Page 94: Right Angle
Chapter 3 Image Quality Troubleshooting 3.3 Print Alignment 3.3.4 Right angle Measure the right angle to reduce the inclination of the ROS and OPC. Measure a horizontal error at the logical value 90 degrees apart 195mm from the center point on the horizontal line.
Page 95: Linearity
Chapter 3 Image Quality Troubleshooting 3.3 Print Alignment 3.3.5 Linearity Confirm the performance of the paper feeding and the ROS in the linearity of vertical line, horizontal line and diagonal line. Measure the distance of the line between A and B, line that passes C. 3-10...
Page 96: Horizontal Level
Chapter 3 Image Quality Troubleshooting 3.3 Print Alignment 3.3.6 Horizontal level Measure the difference between the feeding speeds on the left and right of paper as the horizontal level. Measure the difference of the distance between vertical lines separate 245mm horizontally from the reference length (390mm).
Page 97: Magnification
Chapter 3 Image Quality Troubleshooting 3.3 Print Alignment 3.3.7 Magnification Measure the warping of vertical (paper feeding direction) and warping of horizontal (ROS). Measure the actual line on the center of paper and calculate the ratio to the reference line. Vertical reference line 390mm, Horizontal reference line 245mm.
Page 98: Test Pattern Print
Chapter 3 Image Quality Troubleshooting 3.4 TEST PATTERN PRINT 3.4 TEST PATTERN PRINT The Test Pattern Print is used to print out the test patterns built in the device for operation check. The printing is executed by the PC diagnostic, refer to the Chapter 2. The test printing self patterns are as follows: Number of horizontal solid...
Page 99: Image Quality Fip
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP 3.5 Image Quality FIP FIP-P1 "All white" Phenomenon/Initial check Print sample All white (white paper) No data is printed out, and paper is all white. - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts -...
Page 100: Fip-P2 "All Black
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P2 "All black" Phenomenon/Initial check Print sample Print-out is black. No data is printed out, and paper is all black. - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts -...
Page 101: Fip-P3 "Thin Printing Or Paper Transport Direction Missing
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P3 "Thin printing or paper transport direction missing" Phenomenon/Initial check Print sample Thin printing or paper transport direction missing - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts -...
Page 102: Fip-P4 "Horizontal Missing, Thin Toner On Non-Print Part, Or Whitened Character
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P4 "Horizontal missing, thin toner on non-print part, or whitened character" Phenomenon/Initial check Print sample Light toner is detected in the whole of non-print parts, and whitened letters are printed out. - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage,...
Page 103: Fip-P5 "Obscure Printing
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P5 "Obscure printing" Phenomenon/Initial check Print sample Obscure printing - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts - Drum/toner cartridge (PL10.1.2), ROS ASSY (PL10.1.1)
Page 104: Fip-P6 "Determined Position Missing
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P6 "Determined position missing" Phenomenon/Initial check Print sample Some parts are whitened. (This error occurs at determined positions on paper.) - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts -...
Page 105: Fip-P7 "Cyclic Missing
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P7 "Cyclic missing" Phenomenon/Initial check Print sample Some parts are whitened. (This error occurs cyclically at the same intervals.) - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts -...
Page 106: Fip-P8 "Cyclic Toner On Non-Print Part
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P8 "Cyclic toner on non-print part" Phenomenon/Initial check Print sample Toner is detected in some non-print parts. (This occurs cyclically at the same intervals.) - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts -...
Page 107: Fip-P9 "Toner At Determined Position
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P9 "Toner at determined position" Phenomenon/Initial check Print sample Toner is detected in some non-print parts. (This error occurs at almost determined positions.) - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts -...
Page 108: Fip-P10 "Toner At Random Positions
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P10 "Toner at random positions" Phenomenon/Initial check Print sample Toner on some non-print parts (toner at random) - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts -...
Page 109: Fip-P11 "Blotted Print-Out
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P11 "Blotted print-out" Phenomenon/Initial check Print sample Print-out is blotted. - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts - FUSER ASSY CL CH (PL7.1.15) Action...
Page 110: Fip-P12 "Scattered Toner
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P12 "Scattered toner" Phenomenon/Initial check Print sample Image data is printed with toner scattered. - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts - PLATE DT SAW (PL8.1.4), AZUSA HVPS (PL9.1.6),...
Page 111: Fip-P13 "Dirty Paper Back
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P13 "Dirty paper back" Phenomenon/Initial check Print sample The back of paper is dirty. - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts - FUSER ASSY CL CH (PL7.1.15)
Page 112: Fip-P14 "Wrinkled Paper
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P14 "Wrinkled paper" Phenomenon/Initial check Print sample Paper is waved and wrinkled. - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts - CASSETTE ASSY 250 CL (PL2.1.1) Action...
Page 113: Fip-P15 "Unfused Toner
Chapter 3 Image Quality Troubleshooting 3.5 Image Quality FIP FIP-P15 "Unfused toner" Phenomenon/Initial check Print sample Paper is waved and wrinkled. - Initial check - Are there errors such as use of parts in different specifications, attachment error, damage, transformation, dirt or foreign object? - Major check parts - CASSETTE ASSY 250 CL (PL2.1.1) Action...
Page 114 Chapter 4 Disassembly/Assembly and Adjustment...
Page 115 Chapter 4 Disassembly/Assembly and Adjustment Table of Contents Table of Contents 4.1 Preface ........................4 - 3 4.1.1 Before Work ........................... 4 - 3 4.1.2 Description of procedure........................ 4 - 4 4.2 Disassembly/Assembly....................4 - 5 REP1. Cover........................4 - 5 REP1.1 (SCC) COVER SIDE LEFT CL (PL1.1.1) .................. 4 - 5 REP1.2 (SCC) COVER ASSY RIGHT CL (PL1.1.2)................
Page 116 Chapter 4 Disassembly/Assembly and Adjustment Table of Contents REP5.4 ACTUATOR PAPER EMPTY (PL5.1.18) ................4 - 41 REP5.5 GUIDE PAPER 250 CST R (PL5.1.17) ................... 4 - 42 REP5.6 (SCC) HARNESS ASSY AC IN (PL5.1.46) ................4 - 43 REP5.7 (SCC) GEAR ASSY CST (PL5.1.25)..................4 - 44 REP5.8 (SCC) FEED MOTOR ASSY (PL5.1.28) .................
Page 117: Preface
Chapter 4 Disassembly/Assembly and Adjustment 4.1 Preface 4.1 Preface The ten major items setting correspondence between the equipment and parts list prescribe the removal and replacement procedures of main parts. The adjustment procedures are given in a separate item. - REP 1 Cover - REP 2 Paper Cassette...
Page 118: Description Of Procedure
Chapter 4 Disassembly/Assembly and Adjustment 4.1 Preface 4.1.2 Description of procedure "REP X.Y 'AAAAA'" at the beginning of a procedure means that the part name is "AAAAA". "(PL X.Y)" after a part name in a procedure means that the part corresponds to plate (PL) X and item Y in Chapter 3, "Parts List"...
Page 119: Disassembly/Assembly
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly 4.2 Disassembly/Assembly REP1. Cover REP1.1 (SCC) COVER SIDE LEFT CL (PL1.1.1) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) CAUTION Be careful not to damage the FFC OPP CL (PL1.1.21) in the procedure below.
Page 120: Rep1.2 (Scc) Cover Assy Right Cl (Pl1.1.2)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP1.2 (SCC) COVER ASSY RIGHT CL (PL1.1.2) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) CAUTION Be careful not to damage the FFC OPP CL (PL1.1.21) in the procedure below.
Page 121: Rep1.3 (Scc) Cover Middle Cl (Pl1.1.6)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP1.3 (SCC) COVER MIDDLE CL (PL1.1.6) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) CAUTION Be careful not to damage the FFC OPP CL (PL1.1.21) in the procedure below.
Page 122: Rep1.4 (Scc) Cover Assy Top Cl (Pl1.1.8)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP1.4 (SCC) COVER ASSY TOP CL (PL1.1.8) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Disconnect the FFC OPP CL from CN1 on the ESS PWB.
Page 123: Rep1.5 Plate Gnd Top (Pl1.1.12) [Fg Kit (Main)]
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP1.5 PLATE GND TOP (PL1.1.12) [FG kit (main)] <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Open the COVER ASSY TOP CL. CAUTION Since the COVER ASSY TOP CL is not removed in the procedure below, an excess force may damage the COVER ASSY TOP CL.
Page 124: Rep1.6 Pwba Led (Pl1.1.17)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP1.6 PWBA LED (PL1.1.17) <Removal> Remove the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) toward you and open the COVER ASSY FRONT. Open the COVER ASSY TOP CL. Remove the four screws (gold, tap, 8mm) securing the OPP ASSY CL to the COVER ASSY SUB TOP (PL1.1.9) and move the OPP ASSY CL for 10cm from the COVER ASSY SUB TOP.
Page 125: Rep1.7 (Scc) Cover Assy Stack Cl (Pl1.1.22)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP1.7 (SCC) COVER ASSY STACK CL (PL1.1.22) <Removal> Remove the two screws (gold, with washer, 8mm) securing the COVER ASSY STACK CL and remove the COVER ASSY STACK CL. 1)-1 1)-2 1)-1 AZS411CA <Replacement>...
Page 126: Rep2. Paper Cassette
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP2. Paper Cassette REP2.1 PAD ASSY RETARD 250 (PL2.1.7) <Removal> Remove the CASSETTE ASSY 250 CL from the printer. CAUTION Be careful not to lose the SPRING RETARD 250 in the procedure below. A straight-head screwdriver is recommended for the procedure below.
Page 127: Rep2.2 Guide End 250 Cl (Pl2.1.12)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP2.2 GUIDE END 250 CL (PL2.1.12) <Removal> Remove CASSETTE ASSY 250 CL from the printer. Extend the CASSETTE SLIDE CL to the full and lock it with the LOCK SIDE GUIDE 250 CL (PL2.1.18).
Page 128: Rep2.3 Guide Side L 250 Cl (Pl2.1.13)/Guide Side R 250 Cl (Pl2.1.15)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP2.3 GUIDE SIDE L 250 CL (PL2.1.13)/GUIDE SIDE R 250 CL (PL2.1.15) <Removal> Remove the CASSETTE ASSY 250 CL from the printer. Release two hooks of the LOCK BOTTOM L 250 and remove the LOCK BOTTOM L 250 to right. Release two hooks of the LOCK BOTTOM R 250 and remove the LOCK BOTTOM R 250 to left.
Page 129 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly <Replacement> Perform the removal procedures in the reverse order. When the GEAR GUIDE SIDE (PL2.1.17) attach to the cassette, move the GUIDE NOTE SIDE L to the left end, and then move GUIDE SIDE R to the right end. Be careful not to attach the GUIDE SIDE L and the GUIDE SIDE R to the wrong NOTE position.
Page 130: Rep2.4 Lock Side Guide 250 Cl (Pl2.1.16)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP2.4 LOCK SIDE GUIDE 250 CL (PL2.1.16) <Removal> Remove the GUIDE SIDE R 250 CL. (REP2.3) Set the LOCK SIDE GUIDE 250 CL (PL2.1.16) to the lock position and remove the LOCK SIDE GUIDE 250 CL (PL2.1.16) from the pin of GUIDE SIDE R 250 CL.
Page 131: Rep3. Msi Assy
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3. MSI Assy REP3.1 FRONT UNIT (Reference Only) <Removal> Separate the CASSETTE ASSY 250 CL (PL2.1.1) from the printer by 15cm. Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) toward you, open the COVER ASSY FRONT.
Page 132 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly <Replacement> Perform the removal procedures in the reverse order. 4-18...
Page 133: Rep3.2 Frame Assy Roll Feed (Tray) (Pl3.1.10)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3.2 FRAME ASSY ROLL FEED (TRAY) (PL3.1.10) <Removal> Remove the CASSETTE ASSY 250 CL from the printer. Remove the FRAME BASE RTD TRAY HN. (Refer to REP 3.5) Open the TRAY ASSY FRONT CL (PL3.2.1). Remove ROLL FEED ASSY TRAY.
Page 134: Rep3.3 (Scc) Clutch Roll Feed (Tray) (Pl3.1.20)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3.3 (SCC) CLUTCH ROLL FEED (TRAY) (PL3.1.20) <Removal> Pull the LEVER FRONT R (PL8.1.11) and the LEVER FRONT L (PL8.1.12) toward you, open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) CAUTION Be careful not to damage the FFC OPP CL (PL1.1.21) in the procedure below.
Page 135 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly 3)-3 3)-2 2)-3 Hook 2)-2 Hook 6)-2 5)-2 KON487CA <Replacement> Perform the removal procedures in the reverse order. 4-21...
Page 136: Rep3.4 Roll Feed Assy Tray (Pl3.1.21)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3.4 ROLL FEED ASSY TRAY (PL3.1.21) <Removal> Remove the CASSETTE ASSY 250 CL from the printer. Remove the FRAME BASE RTD TRAY HN. (Refer to REP 3.5) Open the TRAY ASSY FRONT CL (PL3.2.1). Pick the tab of the GUIDE ASSY PAPER TRAY (PL3.1.25) and slide it to the left.
Page 137: Rep3.5 Pad Assy Retard Tray (Pl3.1.23)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3.5 PAD ASSY RETARD TRAY (PL3.1.23) <Removal> Remove the CASSETTE ASSY 250 CL from the printer. Release the hook using the small screwdriver through the left and right holes of FRAME BASE RTD TRAY HN (PL3.1.22), remove the FRAME BASE RTD TRAY HN. Remove the PAD ASSY RETARD TRAY and SPRING RETARD TRAY (PL3.1.24) from the FRAME BASE RTD TRAY HN.
Page 138: Rep3.6 (Scc) Cover Front Right (Pl3.1.30)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3.6 (SCC) COVER FRONT RIGHT (PL3.1.30) <Removal> Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) concurrently toward you, open the COVER ASSY FRONT. Open the TRAY ASSY FRONT CL (PL3.2.1). Release the three hooks of the COVER FRONT RIGHT and rotate the COVER FRONT RIGHT.
Page 139: Rep3.7 (Scc) Cover Front Left (Pl3.1.31)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3.7 (SCC) COVER FRONT LEFT (PL3.1.31) <Removal> Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) concurrently toward you, open the COVER ASSY FRONT. Open the TRAY ASSY FRONT CL (PL3.2.1). Release the three hooks of the COVER FRONT LEFT and rotate the COVER FRONT LEFT.
Page 140: Rep3.8 Tray Assy Front Cl (Pl3.2.1)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3.8 TRAY ASSY FRONT CL (PL3.2.1) <Removal> Remove the FRAME BASE RTD TRAY HN. (Refer to REP 3.5) Open the TRAY ASSY FRONT CL (PL3.2.1). Release the left and right convex of the TRAY ASSY FRONT CL from the hole of the FRAME DUPLEX (PL3.1.2) and remove it.
Page 141: Rep3.9 Plate Assy Btm Tray (Pl3.2.3)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP3.9 PLATE ASSY BTM TRAY (PL3.2.3) Do not disassemble the TRAY ASSY FRONT CL except handling parts in these NOTE procedures. <Removal> Remove the FRAME BASE RTD TRAY HN. (Refer to REP 3.5) Open the TRAY ASSY FRONT CL (PL3.2.1).
Page 142: Rep4. Paper Feeder
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP4. Paper Feeder REP4.1 PLATE HV 1 (PL4.1.4) [FG kit (main)] <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY TOP CL with the FFC OPP CL.
Page 143: Rep4.2 Registration Assy (Pl4.1.30)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP4.2 REGISTRATION ASSY (PL4.1.30) <Removal> Separate the CASSETTE ASSY 250 CL (PL2.1.1) from the printer by 15cm. Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL.
Page 144 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly Hole ACTUATOR ASSY REGI 14)-1 14)-2 Winding once ACTUATOR REGI D 15)-1 15)-1 15)-2 15)-1 15)-1 Boss AZS431CA <Replacement> Perform the removal procedures in the reverse order. Wind the harness of CLUTCH REGI ROLL A (PL4.1.42) into the notch on the frame NOTE of the REGISTRATION ASSY once.
Page 145: Rep4.3 (Scc) Clutch Regi Roll A (Pl4.1.42)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP4.3 (SCC) CLUTCH REGI ROLL A (PL4.1.42) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 146: Rep4.4 Actuator Assy Regi (Pl4.1.19)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP4.4 ACTUATOR ASSY REGI (PL4.1.19) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 147: Rep4.5 Arm Shutter A (Pl4.1.7)/Arm Shutter B (Pl4.1.8)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP4.5 ARM SHUTTER A (PL4.1.7)/ARM SHUTTER B (PL4.1.8) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY TOP CL with FFC OPP CL.
Page 148 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly 8)-1 8)-2 Section A Section A MNR436CA <Replacement> Perform the removal procedures in the reverse order. Rotate the ARM SHUTTER B with the SPRING ARM SHUTTER to clockwise NOTE direction as shown in figure, attach the Section A of the ARM SHUTTER to the rib of FRAME MAIN properly.
Page 149: Rep4.6 Block (Pl4.1.15)/Spring Block (Pl4.1.16) [Backup Piece Kit]
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP4.6 BLOCK (PL4.1.15)/SPRING BLOCK (PL4.1.16) [Backup piece kit] <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB.
Page 150: Rep4.7 Pwba Sensor (Pl4.1.17)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP4.7 PWBA SENSOR (PL4.1.17) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY TOP CL with the FFC OPP CL. (REP1.4) Remove the COVER SIDE LEFT CL.
Page 151: Rep4.8 Harness Assy Crum (Pl4.1.12)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP4.8 HARNESS ASSY CRUM (PL4.1.12) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 152: Rep5. Cassette Guide
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5. Cassette Guide REP5.1 (SCC) GUIDE ASSY CST L (PL5.1.2)/(SCC) GUIDE ASSY CST R (PL5.1.6) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL.
Page 153: Rep5.2 Guide Assy Front (Pl5.1.47)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.2 GUIDE ASSY FRONT (PL5.1.47) <Removal> Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) concurrently toward you, open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 154: Rep5.3 Feeder Assy (Pl5.1.11)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.3 FEEDER ASSY (PL5.1.11) <Removal> Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) concurrently toward you, open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 155: Rep5.4 Actuator Paper Empty (Pl5.1.18)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.4 ACTUATOR PAPER EMPTY (PL5.1.18) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 156: Rep5.5 Guide Paper 250 Cst R (Pl5.1.17)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.5 GUIDE PAPER 250 CST R (PL5.1.17) <Removal> Remove the CASSETTE ASSY 250 CL (PL2.1.1) from the printer. For the next and later procedures, prepare a 3cm or higher bench. NOTE Erect the printer with the rear side down. Release the two hooks of GUIDE PAPER 250 CST R from the FRAME FEEDER (PL5.1.12) and remove the GUIDE PAPER 250 CST R.
Page 157: Rep5.6 (Scc) Harness Assy Ac In (Pl5.1.46)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.6 (SCC) HARNESS ASSY AC IN (PL5.1.46) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 158: Rep5.7 (Scc) Gear Assy Cst (Pl5.1.25)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.7 (SCC) GEAR ASSY CST (PL5.1.25) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 159: Rep5.8 (Scc) Feed Motor Assy (Pl5.1.28)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.8 (SCC) FEED MOTOR ASSY (PL5.1.28) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 160: Rep5.9 Switch P/Size (Pl5.1.29)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.9 SWITCH P/SIZE (PL5.1.29) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 161: Rep5.10 (Scc) Sensor Photo (Pl5.1.32)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.10 (SCC) SENSOR PHOTO (PL5.1.32) <Removal> Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) concurrently toward you, open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 162: Rep5.11 Kit Roll Feed Assy (Pl5.1.60)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP5.11 KIT ROLL FEED ASSY (PL5.1.60) [ROLL FEED FRONT D (PL5.1.35)/ROLL ASSY FEED REAR (PL5.1.36)/GEAR (PL5.1.45)] <Removal> Remove the CASSETTE ASSY 250 CL from the printer. For the next and later procedures, prepare a 3cm or higher bench. NOTE Be careful not to touch the rubber of roll.
Page 163 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly <Replacement> Perform the removal procedures in the reverse order. REP6. 4-49...
Page 164: Rep7. Drive
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP7. Drive REP7.1 (SCC) GEAR ASSY (PL7.1.1) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 165 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly <Replacement> Perform the removal procedures in the reverse order. 4-51...
Page 166: Rep7.2 (Scc) Moter Assy Main (Pl7.1.2)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP7.2 (SCC) MOTER ASSY MAIN (PL7.1.2) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 167: Rep7.3 (Scc) Fuser Assy Cl Ch (Pl7.1.15)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP7.3 (SCC) FUSER ASSY CL CH (PL7.1.15) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 168 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly <Replacement> Perform the removal procedures in the reverse order. The left side screw securing the FUSER ASSY CL CH shall be of the stud type. NOTE Lay the harness of HARNESS ASSY FUSER (PL9.1.7) as shown in figure. NOTE 4-54...
Page 169: Rep7.4 (Scc) Fan (Pl7.1.10)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP7.4 (SCC) FAN (PL7.1.10) <Removal> Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) toward you, open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 170: Rep8. Paper Transportation
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP8. Paper Transportation REP8.1 LEVER FRONT R (PL8.1.11) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER FRONT RIGHT. (REP3.6) Remove the SPRING LEVER F (PL8.1.25). While pressing the bearing of the FRAME FRONT with a straight-head screwdriver, remove the LEVER FRONT R.
Page 171: Rep8.2 Lever Front L (Pl8.1.12)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP8.2 LEVER FRONT L (PL8.1.12) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER FRONT LEFT. (REP3.7) Remove the SPRING LEVER F (PL8.1.25). While pressing the bearing of the FRAME FRONT (PL8.1.2) with a straight-head screwdriver, remove the LEVER FRONT L.
Page 172: Rep8.3 Roll Assy Btr (Pl8.1.13)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP8.3 ROLL ASSY BTR (PL8.1.13) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. In the following procedure, the removal may be started from right or left. NOTE There are the hook of CAP BTR BEARING (PL8.1.19) in the outside of left and NOTE...
Page 173: Rep8.4 Plate Dt Saw (Pl8.1.4)/Chute Trans (Pl8.1.9)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP8.4 PLATE DT SAW (PL8.1.4)/CHUTE TRANS (PL8.1.9) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. CAUTION Since the HARNESS ASSY HV TRANS is mounted in the procedure below, do not lift the CHUTE TRANS too high.
Page 174 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly <Replacement> Perform the removal procedures in the reverse order. CAUTION Replace the five bent tabs of the PLATE DT SAW and attach it. 4-60...
Page 175: Rep8.5 Spring Btr (Pl8.1.6)/Bearing Btr (Pl8.1.7)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP8.5 SPRING BTR (PL8.1.6)/BEARING BTR (PL8.1.7) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the ROLL ASSY BTR. (REP8.3) Loosen the BEARING BTR with a pliers and remove it upward. Remove the SPRING BTR.
Page 176: Rep8.6 Frame Assy Front (Pl8.1.1)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP8.6 FRAME ASSY FRONT (PL8.1.1) <Removal> Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) CAUTION Be careful not to damage the FFC OPP CL (PL1.1.21) in the procedure below.
Page 177 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly 12)-1 12)-1 12)-2 ZS423EC <Replacement> Perform the removal procedures in the reverse order. 4-63...
Page 178: (Scc) Harness Assy Hv Trans (Pl8.1.10)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP8.7 HARNESS ASSY HV BTR (PL8.1.5)/(SCC) HARNESS ASSY HV DT (PL8.1.8)/ (SCC) HARNESS ASSY HV TRANS (PL8.1.10) <Removal> Pull the LEVER FRONT R (PL8.1.11) and LEVER FRONT L (PL8.1.12) toward you and open the COVER ASSY FRONT.
Page 179 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly Hook HARNESS ASSY HV TRANS Hook HARNESS ASSY HV DT HARNESS ASSY HV BTR AZS424CA <Replacement> Perform the removal procedures in the reverse order. Lay the harnesses as shown in figure. NOTE 4-65...
Page 180: Rep9. Frame & Electrical
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9. Frame & Electrical REP9.1 (SCC) FAN ASSY (PL9.1.3) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB.
Page 181: Rep9.2 Chassis Assy Controller (Pl9.1.20)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9.2 CHASSIS ASSY CONTROLLER (PL9.1.20) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 182: Rep9.3 Ess Pwb (Pl9.1.21) (Reference)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9.3 ESS PWB (PL9.1.21) (Reference) <Removal> Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Disconnect the two ESS PWB connectors. Remove the seven screws (4 pcs-board: gold, with washer, 8mm/3 pcs-parallel connector: silver, 8mm) securing the ESS PWB and remove the ESS PWB.
Page 183: Rep9.4 Pwba Mcu Xfabk(B) (Pl9.1.25)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9.4 PWBA MCU XFABK(B) (PL9.1.25) <Removal> Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Disconnect the twelve connectors (P/J100 to P/J111) of the PWBA MCU XFABK(B). Remove the four screws (gold, with washer, 8mm) securing the PWBA MCU XFABK(B) and remove the PWBA MCU XFABK(B).
Page 184: Rep9.5 Cover Assy Pwb (Pl9.1.30)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9.5 COVER ASSY PWB (PL9.1.30) <Removal> Remove the COVER ASSY STACK CL. (REP1.7) Do not remove any screw in the procedure below because there are washers NOTE between the CHASSIS CONTROLLER and COVER ASSY PWB. Fully loosen the three screws (gold, with washer, 10mm) securing the COVER ASSY PWB and lift the back of the COVER ASSY PWB to remove backward.
Page 185: Rep9.6 (Scc) Lvps 230 (Pl9.1.5)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9.6 (SCC) LVPS 230 (PL9.1.5) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 186: Rep9.7 (Scc) Azusa Hvps (Pl9.1.6)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9.7 (SCC) AZUSA HVPS (PL9.1.6) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 187: Rep9.8 Frame Assy Main (Pl4.1.1)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9.8 FRAME ASSY MAIN (PL4.1.1) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 188 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly <Replacement> Perform the removal procedures in the reverse order. 4-74...
Page 189: Rep9.9 Base Chassis Assy (Pl9.1.1)
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP9.9 BASE CHASSIS ASSY (PL9.1.1) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 190 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly 15)-1 15)-1 15)-1 15)-1 ON40GCA Slit Oval hole 15)-2 AZS40HCA <Replacement> Perform the removal procedures in the reverse order. 4-76...
Page 191: Rep10. Xerographics
Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly REP10. Xerographics REP10.1 (SCC) ROS ASSY (PL10.1.1) <Removal> Pull the LEVER FRONT R and LEVER FRONT L toward you and open the COVER ASSY FRONT. Remove the COVER ASSY STACK CL. (REP1.7) Remove the COVER ASSY PWB. (REP9.5) Remove the COVER ASSY TOP CL.
Page 192 Chapter 4 Disassembly/Assembly and Adjustment 4.2 Disassembly/Assembly Hook Hook HARNESS ASSY MOTOR MAIN(PL7.4) Hook Hook (Through CABLE HV) Harness of FAN(PL7.10) Blue Hook Harness of FAN ASSY(PL9.3) CABLE HV(PL9.8) AZS479CA <Replacement> Perform the removal procedures in the reverse order. 4-78...
Page 193 Chapter 5 Parts List...
Page 194 Table of Contents 5.1 Preface.................... 5-1 5.1.1 How to Use Parts List ................5-1 5.1.2 Notice for Use..................5-1 5.1.3 Caution for use of parts list..............5-1 5.2 Parts List ..................5-2 PL1.1 Cover ....................5-2 PL2.1 Paper Cassette..................5-3 PL3.1 MSI Assy (1/2) ..................
Page 195: How To Use Parts List
◆ "HIGH ASSY" in the list represent the high level assembly parts containing that parts. ◆ Parts with (SCC) indicated before the part name in the DESCRIPTION column are Safety Critical Components. User must comply with Fuji Xerox’s regulations on the handling of such components.
Page 196: Parts List
5 - 2 Chapter 5 Parts List 5.2 Parts List 5.2 Parts List ITEM PARTS No. DESCRIPTION PL1.1 Cover 802E 92640 (SCC) COVER SIDE LEFT CL 3210 802K 86760 (SCC) COVER ASSY RIGHT CL (with 3,4) 32B1 COVER SIDE RIGHT 32B2 CLAMP CABLE 32B3...
Page 197: Pl2.1 Paper Cassette
PL2.1 Paper Cassette ITEM PARTS No. DESCRIPTION 050K 56070 CASSETTE ASSY 250 CL (with 2-7,10-26,60-62,65) 5010 1 (with -7,10- 6,60-6 ,65) HOUSING CASSETTE 250 50B1 015K 51000 PLATE ASSY BOTTOM 250 (with 4,5) 50B2 PLATE BOTTOM 250 50B3 PAD 250 50B4 3 (with 4,5) 809E 66830...
Page 198: Pl3.1 Msi Assy (1/2)
5 - 4 Chapter 5 Parts List 5.2 Parts List PL3.1 MSI Assy (1/2) ITEM PARTS No. DESCRIPTION 801K 22350 (SCC) TRAY ASSY CL (with 28,29,32) 5130 FRAME DUPLEX 51B1 007K 93780 GEAR ASSY FRONT A2 (with 4,5) 51B2 PLATE ASSY GEAR FRONT A2 51B3 GEAR 22S 51B4...
Page 199: Pl3.2 Msi Assy (2/2)
PL3.2 MSI Assy (2/2) ITEM PARTS No. DESCRIPTION 801K 22400 TRAY ASSY FRONT CL (with 2-19) 51C4 1 (with 2-19) TRAY FRONT 51C5 015K 73080 PLATE ASSY BTM TRAY 51C6 809E 66820 SPRING PLT BTM 51C7 GUIDE SIDE L TRAY 51C8 GUIDE SIDE R TRAY 51C9...
Page 200: Pl4.1 Paper Feeder
5 - 6 Chapter 5 Parts List 5.2 Parts List PL4.1 Paper Feeder ITEM PARTS No. DESCRIPTION FRAME ASSY MAIN (with 2-17,19,21-23) 5030 0 (with 1-44) 801K 20100 (SCC) FRAME ASSY MAIN (with 3-6,45) 5031 FRAME MAIN 50D1 PLATE HV 1 50D2 PLATE GND 1 50D3...
Page 201: Pl5.1 Cassette Guide
PL5.1 Cassette Guide ITEM PARTS No. DESCRIPTION GUIDE ASSY CST (with 2-9,11-18,20,25-32,35-41,45- 1 (with 2-9,11-18,20,25- 2, 5-41,45-48,60) 032K 98610 5020 48,60) 032K 98620 (SCC) GUIDE ASSY CST L (with 3-5) 50F1 25 (with 26- 2) GUIDE CST L 50F2 PLATE GND GUIDE CST 50F3 (J100) 017E 94640...
Page 202: Pl7.1 Drive
5 - 8 Chapter 5 Parts List 5.2 Parts List PL7.1 Drive ITEM PARTS No. DESCRIPTION 007K 94320 (SCC) GEAR ASSY (with 2,3) 3000 127K 48460 (SCC) MOTOR ASSY MAIN (P1090) 3010 PLATE ASSY GEAR 30B1 (J 09) HARNESS ASSY MOTOR MAIN (J109 - J1090) 30B2 (J 090) 115E 08340...
Page 203: Pl8.1 Paper Transportation
PL8.1 Paper Transportation ITEM PARTS No. DESCRIPTION 801K 22340 FRAME ASSY FRONT (with 2-19) 5300 FRAME FRONT 53B1 003E 64630 BELT FRONT 5311 PLATE DT SAW 53B2 1 (with 2-19) 162K 64680 HARNESS ASSY HV BTR (CN204) 53B3 SPRING BTR 53B4 BEARING BTR 53B5...
Page 204: Pl9.1 Frame & Electrical
5 - 10 Chapter 5 Parts List 5.2 Parts List PL9.1 Frame & Electrical ITEM PARTS No. DESCRIPTION BASE CHASSIS ASSY (with 2,3,PL7.1.10) 3100 101K 52350 CHASSIS ASSY BASE 31B1 (P103) (J30 1) (P104) 127K 48480 (SCC) FAN ASSY (J103) 31B2 (P10 ) (P101)
Page 205: Pl10.1 Xerographics
PL10.1 Xerographics ITEM PARTS No. DESCRIPTION 062K 16310 (SCC) ROS ASSY (J105, J106) 1310 L9.1.5 DRUM / TONER CARTRIDGE * 13B1 *: consumable (J106) (J105) KON508CA 5.2 Parts List 5 - 11 Chapter 5 Parts List...
Page 206: Area Codes For Adjustments/Consumables
5 - 12 Chapter 5 Parts List 5.3 Area Codes for Adjustments/Consumables 5.3 Area Codes for Adjustments/Consumables Environment Area Code Mechanical Adjustment Area Code Troubleshooting error (under User Guide instructions) 9051 Contact Arc 4344 Troubleshooting error (out of User Guide instructions) 9052 Operation error (under User Guide instructions) 9053...
Page 207 Chapter 6 General...
Page 208 Chapter 6 General Table of Contents Table of Contents 6.1 Specifications ......................6 - 3 6.1.1 Device Name/P Code/XJ Code/Product Code................6 - 3 6.1.2 Dimensions and Weight ......................... 6 - 3 6.1.3 Installation Space (min. installation space)..................6 - 3 6.1.4 Printer System Configuration ......................
Page 209 Chapter 6 General Table of Contents 6.1.12.2 Decomposer........................6 - 13 6.1.12.3 Job Control Function......................6 - 13 6.1.12.4 Log Function ........................6 - 14 6.1.12.5 Maintenance ........................6 - 14 6.1.12.6 Power Saver ........................6 - 14 6.1.13 Software Specifications......................6 - 15 6.1.13.1 Firmware Update tool......................
Page 210: Device Name/P Code/Xj Code/Product Code
Chapter 6 General 6.1 Specifications 6.1 Specifications 6.1.1 Device Name/P Code/XJ Code/Product Code Device Name P Code XJ Code Product Code DocuPrint 2050 P-165 XJ-PEP TL300352 6.1.2 Dimensions and Weight Width (mm) Depth (mm) Height (mm) Weight (kg) 598 (maximum) 14.8 (Printer and ESS PWBA,...
Page 211: Printer System Configuration
6.1.4 Printer System Configuration 6.1.4.1 Printer Overview (1) Host Computer Different computers may be connected to DocuPrint 2050 as a host computer. Point-to-point. (2) ESS ESS interprets the print information (control code data, character code data, graphics data, image data etc.) sent from the host computer, converts it into video data and transfers it to the IOT.
Page 212: Iot Functions Overview
Chapter 6 General 6.1 Specifications 6.1.4.2 IOT Functions Overview Configuration Details B/W 21 ppm Recorder 600x600dpi Consumables Drum/toner cartridge (EP Cartridge) Standard: 250-sheet Universal Paper Tray Standard: MSI Plain Paper=30 sheets Paper Supply Postcard=10 sheets Envelope= 5 sheets Label Stock=10 sheets Transparency=10 sheets Output Tray Center output tray (250 sheets)
Page 213: Functions
Chapter 6 General 6.1 Specifications 6.1.7 Functions 6.1.7.1 Recording System Electro-photographic system 6.1.7.2 Exposure System Semiconductor 1 beam laser 6.1.7.3 Development System Development with dry type developer 6.1.7.4 Fixing System Heat fusing of the pressure roll nip system 6.1.7.5 Resolution 600dpi (23.62dots/mm) 6.1.7.6 Operation Mode The printer can be operated in either of 2 operation modes.
Page 214: Paper Throughput
Chapter 6 General 6.1 Specifications 6.1.7.8 Paper throughput Plain paper mode Thick paper mode Paper type Paper slow down slow down Threshold Threshold A3 (SEF) 11.5 11.5 A4 (LEF) 21.0 21.0 A5 (LEF) 18.0 18.0 31 *1 Plain paper B4 (SEF) 12.0 12.0 B5 (LEF)
Page 215: Printing Area
Chapter 6 General 6.1 Specifications 6.1.7.11 Printing Area Usable paper size Minimum and maximum paper size usable for this printer are as follows: Minimum usable paper size : Width 100mm × length 148mm (when using MSI) Maximum usable paper size : Width 297mm × length 420mm (when using MSI) Maximum printable area For each printable size of paper, this printer masks 5mm within the left edge and right edge, 5mm from within edge and back edge as unprintable area, in order to prevent from that images exceed...
Page 216: Input Properties
Chapter 6 General 6.1 Specifications 6.1.7.12 Input Properties Paper pick-up system Paper pick-up with paper tray Feeding method of this printer is FRPF method. MSI paper pick-up The MSI (Multi Sheet Inserter) is equipped as standard. Selection of MSI is designated from the controller.
Page 217: Paper
Basis weight 420 × 364 × 297 × 279.4 × 257 × 210 × type 215.9 Fuji Xerox P 64g/m Fuji Xerox P thick 78g/m Fuji Xerox C2 68g/m Fuji Xerox EP-R 67g/m Fuji Xerox WR100 67g/m Xerox 3R9**** 80g/m RX80...
Page 218: Operating Environment
Chapter 6 General 6.1 Specifications 6.1.8 Operating Environment 6.1.8.1 Installation Temperature / Humidity Installation temperature and humidity on the condition without condensation is as follows. At operating : 5-32 °C, 15-85%RH At stopping : minus 20-40 °C, 5-85%RH 6.1.8.2 Installation Altitude 0 to 2,500m 6.1.8.3 Installation Horizontality Lateral levelness of table surface on which the printer is installed: 5 degrees...
Page 219: Print Image Quality
The print image quality specified here is guaranteed with standard paper fed from the paper tray. The evaluation is performed with paper. Fuji Xerox P paper A3 Paper condition The paper used is fresh paper immediately after unpacked, which has been left in the operating environment for 12 hours before unpacking.
Page 220: Controller Specifications
Chapter 6 General 6.1 Specifications 6.1.12 Controller Specifications 6.1.12.1 External Interface 1) USB Item Specifications Connector Type B x1 Protocol Compliance with USB 2.0. High Speed capable Support Client Windows98 /Me/2000/XP/2003 Server, USB standard device *1 : Supports after Windows98SE 2) IEEE1284 Item Specifications...
Page 221: Log Function
Chapter 6 General 6.1 Specifications 6.1.12.4 Log Function Counter Function Total page Counter This counter is counting the whole printing page except jammed page. The maximum count value is one million. Toner cartridge page Counter This counter is counting the printing page for the Drum/toner cartridge (EP Cartridge).
Page 222: Software Specifications
Chapter 6 General 6.2 Tools and Service Consumables 6.1.13 Software Specifications 6.1.13.1 Firmware Update tool This tool operates in a Windows environment. This tool operates with USB, 1284 and Port9100. Tool Name: FWDL tool 6.1.13.2 Client Hardware Hardware Guaranteed Conditions Remarks PC/AT Operation is guaranteed with Windows98, Me,...
Page 223: Installation Procedure
Chapter 6 General 6.5 Installation Procedure 6.5 Installation Procedure 6.5.1 Confirming the components packed together with this printer Check that all items listed below are in the box. 1) Main unit 2) Drum/toner cartridge (2K) 3) Power cable 4) CD-ROM Remove the printer from the box and carry it to the installation location.
Page 224 Chapter 6 General 6.5 Installation Procedure When the printer is first taken out of the box, the paper tray of the printer is taped as shown in the diagram. Remove these pieces of tape. 6-17...
Page 225: Installing The Drum/Toner Cartridge
Chapter 6 General 6.5 Installation Procedure 6.5.2 Installing the Drum/Toner Cartridge When handling the drum/toner cartridge, take note of the following points: WARNING Never throw a drum/toner cartridge into an open flame. Toner remaining in the cartridge can cause an explosion and you can get burnt. •...
Page 226 Chapter 6 General 6.5 Installation Procedure Place the drum/toner cartridge on a flat surface and pull out the seal horizontally. Important • When pulling out the seal, pull it out horizontally. The tape might break if it is pulled out at an angle. •...
Page 227: Connecting Interface Cable And Power Cord
Chapter 6 General 6.5 Installation Procedure 6.5.3 Connecting Interface Cable and Power Cord Select an interface cable and connect it to the printer. Important • Connect the USB cable only after the print driver has been installed on the computer. Connect the interface cable to the interface connector on the back of the printer.
Page 228: Loading Paper In Paper Tray
Chapter 6 General 6.5 Installation Procedure 6.5.4 Loading Paper in Paper Tray This section explains how to load A4 size plain paper in the landscape orientation in the paper tray. Portrait orientation Landscape orientation Hold the paper tray with both hands and pull it out gently by lifting up the tray slightly.
Page 229 Chapter 6 General 6.5 Installation Procedure Load the paper with the side to be printed facing up and with all four corners aligned. NOTE • Do not fan paper to separate a ream. It causes static electricity, which can lead to paper jams. •...
Page 230: Installing The Print Driver And Setting Up The Usb Port
Chapter 6 General 6.5 Installation Procedure 6.5.5 Installing the Print Driver and Setting Up the USB Port To print from the computer, install the software, such as the print driver and SimpleMonitor. The print driver is software that converts print data and instructions from the computer to a format that can be interpreted by the printer.
Page 231 Chapter 6 General 6.5 Installation Procedure Select [I accept the terms of the license agreement] and click [Next]. Select [FX DocuPrint 2050] and then click [Next]. Print Driver The detected printers and the information about them are displayed. Select the printer to be installed.
Page 232 Chapter 6 General 6.5 Installation Procedure Confirm the printer settings acquired from the print driver, and then click [Next]. To modify the printer settings, click [Change]. Select the software and documentation to be installed, and then click [Install]. To change the software settings, select the software from the list and click [Change].
Page 233 Chapter 6 General 6.5 Installation Procedure Setting Up the USB Port Make sure that the printer is off, and connect the USB cable. Switch on the printer. When the following dialog box appears, click [Next]. The computer automatically detects the new hardware and installs necessary software. This concludes setup of the USB port. From the [start] menu, click [Printers and Faxes] (or [Settings] >...
Page 234: When Using Windows Me Or Windows 98
Chapter 6 General 6.5 Installation Procedure 6.5.5.2 When Using Windows Me or Windows 98 To use the printer with a USB connection, install the USB print utility first. Then, install the print driver and set up the USB port. If you print through a parallel connection, you do not need to install the USB print utility.
Page 235 Chapter 6 General 6.5 Installation Procedure Select [Yes, I want to restart my computer now], and then click [Finish]. Restart your coumputer. Installing Print Driver Insert the Software Pack CD-ROM into the CD-ROM drive. The [Printer Software CD-ROM Menu] dialog box appears automatically. Click [Print Driver Installation].
Page 236 Chapter 6 General 6.5 Installation Procedure Select [I accept the terms of the license agreement] and click [Next]. Select [FX DocuPrint 2050] and then click [Next]. Print Driver The detected printers and the information about them are displayed. Select the printer to be installed.
Page 237 Chapter 6 General 6.5 Installation Procedure Confirm the printer settings acquired from the print driver in the previous step, and then click [Next]. To modify the printer settings, click [Change]. Select the software and documentation to be installed, and then click [Install]. To change the software settings, select the software from the list and click [Change].
Page 238 Chapter 6 General 6.5 Installation Procedure Setting the USB port Make sure that the printer is off, and connect the USB cable. Switch on the printer. The computer automatically detects the new hardware and the USB port is made. From the [Start] menu, click [Settings] and then [Printers]. Click the icon of the printer, and then click [Properties] from the [File] menu.
Page 239 From the [Start] menu, click [Settings] and then [Control Panel]. Double-click [System]. In the [System Properties] dialog box, click the [Device Manager] tab and delete [FX DocuPrint 2050] in [Other Devices]. Remove the USB cable, and then connect it again. From the [Start] menu, click [Settings] and then [Printers].
Page 240: Installing Simplemonitor
Chapter 6 General 6.5 Installation Procedure 6.5.5.3 Installing SimpleMonitor SimpleMonitor is software that allows you to check the status of the printer and stop print jobs in progress from the computer. When SimpleMonitor is installed, the SimpleMonitor icon will be displayed on the taskbar at the bottom right of the screen. Double-click the icon and then select the printer in the [Select Printer] dialog box.
Page 241 Chapter 6 General 6.5 Installation Procedure Select [I accept the terms of the license agreement] and click [Next]. Select the software to be installed and then click [Install]. To change the destination of the software, click [Change]. Click [Finish] to complete the installation. 6-34...
Page 242: Test Printing
Click [start], and then select [Control Panel]. Double click [Add or Remove Programs] on the [Control Panel] dialog box. Click the [Change or Remove Programs] icon. Select [Fuji Xerox SimpleMonitor for Asia-Pacific], and then click the [Change/Remove] button. Follow the on-screen instructions to complete the uninstallation.
Page 243 Chapter 7 Wiring Data...
Page 244 Chapter 7 Wiring Data Table of Contents Table of Contents 7.1 Connector [P (plug) / J (jack)]..................7 - 2 7.1.1 List of P/J ............................7 - 2 7.1.2 IOT P/J layout diagram ........................7 - 3 7.2 General Wiring Diagram ....................7 - 5 7.3 Wiring Diagram between Parts..................7 - 7 7.3.1 Configuration..........................
Page 245: Connector [P (Plug) / J (Jack)]
Chapter 7 Wiring Data 7.1 Connector [P (plug) / J (jack)] 7.1 Connector [P (plug) / J (jack)] 7.1.1 List of P/J Coordiates Remarks H-209 Connection between PWBA MCU and HARNESS ASSY PH G-209 Connection between PWBA MCU and CABLE SENSOR G-210 Connection between PWBA MCU and CABLE HV F-210...
Page 246: Iot P/J Layout Diagram
Chapter 7 Wiring Data 7.1 Connector [P (plug) / J (jack)] 7.1.2 IOT P/J layout diagram CN206(VD) CN205(VG) CN204(TR) P/J500 P/J1110 CN201 CN203 P/J1001 P/J301 MOTOR ASSY (HVPS) FEED (LVPS) SENSOR PHOTO SENSOR (MSI) SWITCH PHOTO P/SIZE P/J302 P/J1002 P/J1003 CN202(DB) P/J303B (PWBA...
Page 247 Chapter 7 Wiring Data 7.1 Connector [P (plug) / J (jack)] P/J3021 P/J107 P/J111 P/J108 CN4 CN1 P/J109 CN104 CN103 P/J110 P/J1090(CN101) (PWBA SENSOR) MOTOR ASSY MAIN (PWBA ESS) (PWBA MCU) CN102 CN101 P/J106 P/J100 P/J105 P/J104 P/J101 P/J103 P/J102 ON701CA...
Page 248: General Wiring Diagram
Chapter 7 Wiring Data 7.2 General Wiring Diagram 7.2 General Wiring Diagram This section explains how to understand the entire connection wiring diagram shown in the next page. <<To be continued to the next page>>...
Page 249 Chapter 7 Wiring Data 7.2 General Wiring Diagram <<Continued from the preceding page>> §2 §1 FUSER ASSY CL CH LVPS 230 HARNESS ASSY AC IN PL7.1.15 PL5.1.46 PL9.1.5 Halogen P/J3021 P/J302 P/J301 Inlet Thermostat §3 Thermistor Sensor Exit §9 P/J108 CN103 CN104 MOTOR ASSY...
Page 250: Wiring Diagram Between Parts
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts 7.3 Wiring Diagram between Parts 7.3.1 Configuration The connection wiring diagram is divided into 9 sections to show the connection between parts in detail. § 1 PWBA MCU <-> LVPS <-> HARNESS ASSY AC IN Connection between PWBA MCU and LVPS Connection between LVPS and HARNESS ASSY AC IN §...
Page 251: Notes On Using The Wiring Diagram Between Parts
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts 7.3.2 Notes on Using the Wiring Diagram between Parts This section explains how to understand the part-to-part connection wiring diagram shown in the next and subsequent pages. However, the explanation of the general symbols are omitted. <<To be continued to the next page>>...
Page 252 Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts <<Continued from the preceding page>>...
Page 253: Pwba Mcu <-> Lvps <-> Harness Assy Ac In
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 1 PWBA MCU <-> LVPS <-> HARNESS ASSY AC IN PWBA MCU LVPS 230 XFABK(B) PL9.1.5 HARNESS ASSY P/J108 PL9.1.25 AC IN RelayControl(H) PL5.1.46 P/J301 HeaterControl(H) AC N AC L 5VDC 24VDC 24VDC...
Page 254: Lvps <-> Fuser Assy
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 2 LVPS <-> FUSER ASSY FUSER ASSY CL CH LVPS 230 PL7.1.15 PL9.1.5 P/J3021 P/J302 AC N Halogen AC L [HARNESS ASSY FUSER PL9.1.7] Thermostat KON656CA Signal line name Reference AC N Neutral side of AC input near the power (heater TRIAC power voltage) AC L...
Page 255: Pwba Mcu <-> Pwba Sensor <-> Fuser Assy, Clutch Regi Roll
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 3 PWBA MCU <-> PWBA SENSOR <-> FUSER ASSY, CLUTCH REGI ROLL PWBA MCU PWBA SENSOR FUSER ASSY CL CH XFABK(B) PL4.1.17 PL7.1.15 PL9.1.25 P/J101 CN101 RegistClutch (L) Sensor Exit CN103 24VDC PaperExit (L)
Page 256: Pwba Mcu <-> Hvps, Drum/Toner Cartridge (1/2)
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 4 PWBA MCU <-> HVPS, Drum/toner cartridge (1/2) PWBA MCU AZUSA HVPS XFABK(B) PL9.1.6 PL9.1.25 P/J102 CN201 Standard Voltage T-Roller V-mom CR_DC On/Off T- On/Off (L) T+ On/Off (L) TR D/A Output DB_DC D/A Output DB_AC D/A Output DB_AC Clock...
Page 257: Pwba Mcu <-> Hvps, Drum/Toner Cartridge (2/2)
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 4 PWBA MCU <-> HVPS, Drum/toner cartridge (2/2) Signal line name Reference Standard Voltage Toner empty reference voltage T-Roller V-mon (L) H-VOLT and erase control signal T-On/Off (L) Transfer (-) output control signal T+On/Off (L) Transfer (+) output control signal TR D/A Output...
Page 258: Pwba Mcu <-> Ros Assy
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 5 PWBA MCU <-> ROS ASSY PWBA MCU ROS ASSY PL10.1.1 XFABK(B) PL9.1.25 Scanner P/J105 Motor 24VDC ScanMotorDrive(LowAct)(L) ScanMotorLock (L) ScanMotorClock 24VDC LD ASSY P/J106 LD PowerControl LD Monitor HSYNC Signal (L) InterLock5V LDOn/Off (L) Video Data...
Page 259: Pwba Mcu <-> Pwba Ess <-> Pwba Led (1/2)
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 6 PWBA MCU <-> PWBA ESS <-> PWBA LED (1/2) ESS PWB PWBA MCU PL9.1.21 XFABK(B) PL9.1.25 P/J107 CPRDY (L) PRINT (L) CBSY (L) CMD (L) CCLK (L) PWBA LED PL1.1.17 VDO (L) P/J500...
Page 260: Pwba Mcu <-> Pwba Ess <-> Pwba Led (2/2)
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 6 PWBA MCU <-> PWBA ESS <-> PWBA LED (2/2) Signal line name Reference CPRDY (L) Controller ready signal PRINT (L) Print control signal CBSY (L) Controller busy signal CMD (L) Command control signal CCLK Controller Clock signal...
Page 261: Pwba Mcu <-> Sensor Photo, Switch P/Size, Motor Assy Feed
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 7 PWBA MCU <-> SENSOR PHOTO, SWITCH P/SIZE, MOTOR ASSY FEED PWBA MCU SENSOR PHOTO XFABK(B) PL5.1.32 PL9.1.25 P/J100 P/J1001 1st HP No Paper SNS (L) 5VDC 1st HP PaperSize SW C Status 1st HP PaperSize SW B Status SWITCH P/SIZE 1st HP PaperSize SW A Status...
Page 262: Pwba Mcu <-> Clutch Roll Feed (Tray), Sensor Photo, Fan
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 8 PWBA MCU <-> CLUTCH ROLL FEED (TRAY), SENSOR PHOTO, FAN PWBA MCU SENSOR PHOTO XFABK(B) PL3.1.13 PL9.1.25 P/J1102 P/J303 P/J303B P/J110 5VDC NO PAPER SNS (L) InterLock24V MSI ClutchDrive (L) CLUTCH ROLL FEED (TRAY) P/J1101...
Page 263: Pwba Mcu <-> Motor Assy Main, Fan Assy
Chapter 7 Wiring Data 7.3 Wiring Diagram between Parts § 9 PWBA MCU <-> MOTOR ASSY MAIN, FAN ASSY PWBA MCU MOTOR ASSY MAIN PL7.1.2 XFABK(B) PL9.1.25 : The number is CN101 P/J1090 P/J109 MainMotorLockSignal(L) printed on the board. MainMotorDrive 5VDC InterLock24V [HARNESS ASSY MOTOR...
Page 264 Chapter 10 Machine Overview...
Page 265 Chapter 10 Machine Overview Table of Contents Table of Contents 10.1 Print Process ......................10 - 2 10.1.1 Outline of Print Process ......................10 - 2 10.1.2 Explanation of Print Process...................... 10 - 3 10.2 Print Data Flow ......................10 - 9 10.3 Drive Transmission Route ...................10 - 10 10.4 Paper Transport....................10 - 11 10.5 Functions of Major Components................10 - 12...
Page 266: Print Process
Chapter 10 Machine Overview 10.1 Print Process 10.1 Print Process 10.1.1 Outline of Print Process In this device, the print process consists of the seven basic steps to form a toner image on the drum surface, transfer the toner image to paper, and fix (fuse) the transferred image to paper. While the drum surface repeats steps 1 to 5 and 7, paper passes through steps 4 to 6.
Page 267: Explanation Of Print Process
Chapter 10 Machine Overview 10.1 Print Process 10.1.2 Explanation of Print Process [Charge] This steps discharges BCR (Bias Charge Roll) in the Drum/toner cartridge to charge the drum surface (external surface of the optical electric-conductor) with even minus power. - BCR, that is a conductive roller, comes into contact with the drum, and receives the discharge voltage from the HVPS.
Page 268 Chapter 10 Machine Overview 10.1 Print Process [Exposure] This step scans the drum surface charged with minus power by laser beams, and forms a latent electrostatic image on the drum surface. - Laser beams are radiated according to print data sent from the printer controller. When print data instructs the system to print black pixel dots, laser beams are output;...
Page 269 Chapter 10 Machine Overview 10.1 Print Process [Developing] This step draws toner on an invisible latent electrostatic image on the drum surface and forms a visible toner image on the drum. - This device uses dry-type one-component magnetic toner. Toner is supplied from the toner room to the magnet roll adjacent to the drum surface in the Drum/toner cartridge by the agitator.
Page 270 Chapter 10 Machine Overview 10.1 Print Process [Transfer] This step transfers a toner image generated on the drum surface onto paper using the BTR (Bias Transfer Roll) in the BTR ASSY. - The BTR, that is a conductive roller, comes into contact with the drum, and receives the high voltage from the HVPS.
Page 271 Chapter 10 Machine Overview 10.1 Print Process [Fusing] This step dissolves toner on paper and fixes a toner image on paper by pressure. - The toner image transferred from the drum is so fine than it is destroyed only by slightly touching it by fingers.
Page 272 Chapter 10 Machine Overview 10.1 Print Process [Cleaning] The cleaning is divided into three types: physical drum cleaning, electric drum cleaning, and electric BTR cleaning. - Physical drum cleaning This system removes the remaining toner on the drum surface. The remaining toner on the drum surface without being transferred in the [transfer] step is scratch-removed by the cleaning blade coming into contact with the drum surface.
Page 273: Print Data Flow
Chapter 10 Machine Overview 10.2 Print Data Flow 10.2 Print Data Flow Print data, that is sent from the printer controller, changes to print image through the following flow: Latent electrostatic image on drum Host (electric signal) Printer controller (electric signal) Toner image on drum (visible image) PWBA MCU (electric signal) Toner image on paper...
Page 274: Drive Transmission Route
Chapter 10 Machine Overview 10.3 Drive Transmission Route 10.3 Drive Transmission Route The torque of the Main Motor in the GEAR ASSY DRIVE changes to the driving forth through the driving gear, and transmitted in the following flow. MOTOR ASSY FEED(Paper feeding gear) IDLE EAR 33 EAR FEED 39-20 DRUM / TONER...
Page 275: Paper Transport
Chapter 10 Machine Overview 10.4 Paper Transport 10.4 Paper Transport Paper is transported in the following sequence: Cassette paper feeding Tray paper feeding Paper feeding by Paper feeding by ROLL FEED FRONT D and ROLL FEED ASSY TRAY ROLL FEED REAR 2 Transport by ROLL ASSY REGI in REGISTRATION ASSY and ROLL ASSY PRESS Transport by drum in DRUM / TONER CARTRIDGE and BTR in ROLL ASSY BTR Transport by HEAT ROLL and PRESSURE ROLL...
Page 276: Functions Of Major Components
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5 Functions of Major Components This section explains the major functional parts composing this device, giving an illustration. The component configuration is divided into eight blocks to hold the relation with the parts list. 10.5.1 Paper Cassette 10.5.1.1 Major Functions [Paper Cassette] - The paper cassette is used to accommodate and feed general papers.
Page 277: Paper Feeder
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.2 Paper Feeder 10.5.2.1 Major Functions [Paper Feeder] - ROLL FEED FRONT D Rotates, receiving the driving force from the MOTOR ASSY FEED, and outputs paper from the paper cassette. - ROLL ASSY REGI Transports the paper fed from the paper cassette by the driving force of the MOTOR ASSY FEED, using the ROLL ASSY REGI that receives the driving force by the MOTOR ASSY MAIN.
Page 278: Paper Transportation
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.3 Paper Transportation 10.5.3.1 Major Functions [Paper Transportation] This device transports paper between the drum and ROLL BTR so that a toner image on the drum is positioned correctly, using the ROLL ASSY PRESS and ROLL ASSY REGI. This device also transmits the transfer voltage output by the HVPS to the ROLL BTR via the BEARING BTR, and neutralizes the charge of the paper transferred by the PLATE DT SAW to peel paper from the drum.
Page 279: Reference Figure [Paper Transportation]
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.3.2 Reference Figure [Paper Transportation] DRUM / TONER C RTRIDGE PL TE DT S W ROLL BTR ROLL SSY REGI ROLL SSY PRESS REGI SENSOR CTU TOR SSY REGI KON1004C 10-15...
Page 280: Fuser And Paper Exit
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.4 Fuser and Paper Exit 10.5.4.1 Major Functions [Fuser & Paper Exit] FUSER ASSY Consists of the HEAT ROLL, PRESSURE ROLL, HALOGEN LAMP, THERMISTOR, THERMOSTAT, SENSOR ACTUATOR, ROLL ASSY EXIT, SENSOR EXIT, SEPARATOR, and so on. The FUSER ASSY fixes toner not yet fixed on paper with heat and pressure and then ejects paper.
Page 281: Reference Figure [Fuser & Paper Exit]
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.4.2 Reference Figure [Fuser & Paper Exit] ROLL ASSY EXIT SENSOR ACTUATOR pinch roll PRESSURE ROLL SENSOR EXIT SEPARATOR HEAT ROLL AZS528CA 10-17...
Page 282: Frame And Drive
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.5 Frame and Drive 10.5.5.1 Major Functions [Drive] - GEAR ASSY DRIVE Consists of the MOTOR ASSY MAIN and driving gear that transmits the driving force of the MOTOR ASSY MAIN to each part, and performs the mechanical driving by rotation of the MOTOR ASSY MAIN.
Page 283: Xerographics
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.6 Xerographics 10.5.6.1 Major Functions [Xerographics] ROS ASSY The ROS ASSY is a laser beam output unit that consists of the LD Assy, SCANNER Assy, lens, mirror, window, and so on. In this manual, the ROS ASSY is simply called ROS. - The LD ASSY converts the received electric signals to laser beams by the laser diode at emission.
Page 284: Reference Figure [Xerographics]
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.6.2 Reference Figure [Xerographics] [ROS ASSY] [Drum/toner cartridge] 10-20...
Page 285: Electrical
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.7 Electrical 10.5.7.1 Major Functions [Electrical] PWBA ESS (Reference) Controls the entire printer (drawing control and entire printer operation control). - Processes (drawing, etc.) data received from the host and controls the steps executed to printing. - Sends the commands required to run the mechanism to the PWBA MCU.
Page 286: Reference Figure [Electrical]
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.7.2 Reference Figure [Electrical] PWBA ESS PWBA MCU LVPS HVPS INTERLOCK SWITCH FAN ASSY PWBA SENSOR AZS563CA COVER TOP INTERLOCK SWITCH COVER ASSY FRONT AZS533CA 10-22...
Page 287: Msi Assy
Chapter 10 Machine Overview 10.5 Functions of Major Components 10.5.8 MSI Assy 10.5.8.1 Major Functions [MSI Assy] ROLL FEEDER ASSY TRAY Transports the paper fed from the MSI by the driving force of the MOTOR ASSY MAIN. CLUTCH ROLL FEED (TRAY) Starts operation the predetermined time after the SENSOR PHOTO senses paper, transmits the driving force the gear unit to the ROLL FEED ASSY TRAY.
Page 288 PUBLICATION COMMENT SHEET Use this feedback sheet to make us aware of the strengths and weaknesses of the material you have received. Please comment on adequacy, quality, usability, format, parts of manual not used, etc. Specific errors or deficiencies should be referenced by page and/or page number. Mail to your Technical Support Department and they will pass to us.

Fuji Xerox DocuPrint 2050 Service Manual

Preface

Chapter 1 Service Call Procedure

Table of Contents

Chapter 3 Image Quality Troubleshooting

Chapter 4 Disassembly/Assembly and Adjustment

Chapter 5 Parts List

Chapter 6 General

Chapter 7 Wiring Data

Chapter 10 Machine Overview

Quick Links

Chapters

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fuji Xerox DocuPrint 2050

Summary of Contents for Fuji Xerox DocuPrint 2050
