Figure B-10 Audio Ports; Figure B-11 Audio Line-Out Connector; Figure B-12 Audio Line-In Connector; Table B-10 Audio Ports - Sun Microsystems SPARC classic Service Manual

FIGURE B-10
TABLE B-10
Line-Out
Left Channel
Right Channel
Return
B.11 Signals for the Audio Ports
B.11.1 Audio Line-Out Connector
FIGURE B-11
This connector is used to connect the system audio output to a stereophonic
amplifier and external loudspeakers.
B.11.2 Audio Line-In Connector
FIGURE B-12
B-10 SPARCclassic/SPARCclassic X/SPARCstation LX Service Manual • November 1993
Audio Ports
Audio Ports
Line-In
Left Channel
Right Channel
Return
Audio Line-out Connector
Audio Line-in Connector
