Using Trivu To Clear Nvram - Javad TRIUMPH-1 Operator's Manual

Receiver and File Maintenance
Clearing the NVRAM

Using TriVU to Clear NVRAM

4. Wait until the four LEDs blink yellow.
5. Release the FN key.
5.5.2. Using TriVU to Clear NVRAM
1. Connect your receiver and computer. See "Connecting the Receiver and a Computer" on
page 37 for this procedure.
2. Start TriVU. Select the COM port and click Ok (Figure 5-7).
3. Click the Tools Clear NVRAM (Figure 5-11).
4. Click OK at the clear NVRAM confirmation dialog box. The REC LED rapidly flashes
green and red; the SAT LED flashes red.
The receiver will automatically disconnect once the NVRAM is cleared.
88
Figure 5-10. Connection Parameters
Figure 5-11. Clear NVRAM
