Parameter
Baud rate
RTS/CTS
Figure 3-19. Base and Rover Configuration for RTK – Ports - If Internal UHF modem is used
www.javad.com
Base Receiver
Select a baud rate to use for transmitting differential messages from the receiver
board to the modem module.
The baud rate must match the modem's serial port speed.
Select to enable handshaking.
Configuration
Configuring the Receiver
Configuring the External UHF Modem
Rover Receiver
63
