Configuration
Configuring the Internal/External UHF Modem/GSM Module

Configuring the GSM module for Point-to-Point radio link

2. When finished, click File Disconnect.
3.1.2. Configuring the GSM module for Point-to-Point radio link
Note:
To comply with RF exposure requirements, maintain at least 20 cm between the user and the
GSM modem.
1. On the General tab, set the following parameters (Table 3-2) and click Apply (Figure 3-4
on page 49). In this tab modem and service status and possible errors are displayed.
Parameter
Mode
PIN
48
Figure 3-3. Radio Link tab
Table 3-2. Receiver Parameters for the General Tab
Base Receiver
Slave
Enter a Personal Identification Number (PIN) if required.
Rover Receiver
Master
