1. Connect your receiver and computer. See "Connecting the Receiver and a Computer" on
page 37 for this procedure.
2. Start TriVU. Select the COM port and click Ok (Figure 3-13).
3. Click the Configuration Receiver and open the MinPad tab. Set the following
parameters and click Apply. See the following pages for descriptions of these parameters.
• Recording interval on page 68.
• Elevation mask for log file on page 68.
• File name prefix on page 68.
• Always append to the file on page 69.
• Files Creation mode on page 69.
• Automatic File Rotation Mode (AFRM) on page 69.
www.javad.com
Figure 3-24. Connection Parameters
Configuration
MinPad Configuration
Configuring the External UHF Modem
