A.1.5. GSM Module Details
Table A-5 lists the internal general specifications for the internal modem connection for an
optional GSM module.
Operating Systems
Tx power
Typical RX sensitivity
GPRS
EDGE – Model Dependent
CSD
SMS
One serial port
UART
SIM Card
Connectors
Regulatory and Approvals
150
Table A-5. GSM Module Specifications
Quad band: 850/900/1800/1900 MHz
850/900 MHz – Class 4 (2 Watt)
1800/1900 MHz – Class 1 (1 Watt)
-106dBm (4dB margin on top of spec)
Multi-slot class 10 (4 down; 2 up; 5 Total)
Max BR 85.6 Kbps
Class B GSM 07.10 multiplexing protocol
Coding scheme CS1-CS4
Embedded TCP/IP and UDP/IP protocol stack
Embedded FTP
Embedded SMTP/POP3 – e-mail
SSL – Secure Connection
Multi-slot class 10 (4 Down; 2 Up; 5 Total)
Max BR Downlink 236.8 Kbps (Over RS232)
Coding Scheme MCS1-MCS9
Max BR 14.4 Kbps
MO/MT Text and PDU modes
Cell broadcast
Data and Command port
BR from 300 bps to 460 Kbps, Auto BR
2 SIM cards support, 3.0 V, STK 3.1
RF MMCX
FCC, IC, CCC
FTA, PTCRB
R&TTE
GCF
EMC
QS9000 manufacturing
RoHS/WEEE
