Javad TRIUMPH-1 Operator's Manual page 52

Configuration
Configuring the Internal/External UHF Modem/GSM Module
Configuring the GSM module for Internet access
3. In the Service tab Main subtab specify the following parameters (Table 3-5) and click
Apply (Figure 3-8 on page 53).
Parameter
Mode
52
Figure 3-7. GPRS tab
Table 3-5. Receiver Parameters for the Service Tab Main Subtab
•OFF means service is disabled.
•RCV means that modem will receive data from another (remote) JAVAD GNSS
receiver configured as a base station. This base station have to be connected with
Internet via Ethernet or GPRS and have static IP address.
•NTRIP are useful to provide a method to establish connection to an NTRIP caster,
request data from particular mount point, and then receive and use the data as RTK/
DGPS corrections.
•SERVER - this mode allows working with JAVAD server.
Value
