Javad TRIUMPH-1 Operator's Manual page 110

Configuration Examples
Satel Protocol Configuration Example
Base Station Configuration
7. Start TriVU. Select port the receiver is connected to and click OK (Figure 6-56).
8. Click Configuration Receiver.
9. In the Base tab click the Get from receiver button. Reference geodetic coordinates appear.
Click Apply (Figure 6-57).
110
Figure 6-29. TriVU. Selecting port
Figure 6-30. Base tab
