10. In the Ports tab set the Port D Output mode to RTK CMR, and click Apply, then OK
(Figure 6-58).
11. Click File Exit to quit TriVU.

6.2.2. Rover Configuration

1. Start ModemVU.
2. Select Triumph 1X Internal Radio and click OK (Figure 6-8).
www.javad.com
Figure 6-31. Rover tab
Figure 6-32. ModemVU. Options window
Configuration Examples
Satel Protocol Configuration Example
Rover Configuration
111
