4. In the General tab click Set all parameters to defaults and set up the antenna parameter:
Auto, Internal or External, when external antenna is used.(Figure 3-14).
5. Click the MinPad tab and configure the following settings (Table 3-6), then click Apply
(Figure 3-15 on page 60).
Parameter
Recording interval
Elevation mask angle
File name prefix
www.javad.com
Figure 3-14. Set all parameters to defaults
Table 3-6. Receiver Parameters for the MinPad Tab
Base Receiver
Enter 15 seconds.
Enter 15 degrees.
Enter a unique ID, such as the last 3 digits of receiver's serial number.
Configuration
Configuring the Receiver
Configuring the External UHF Modem
Rover Receiver
