Settings For The Server Subtab - Javad TRIUMPH-1 Operator's Manual

• Port - The value of this field should match the IP port the NTRIP caster is listening on for
connections.
• User - This parameter specifies user ID for the protected space of the requested mount
point.Only basic authentication scheme is supported. If empty, no user or password values
will be sent to the NTRIP caster.
• Password - This field specifies the password for the protected space of the requested
mount point. Only basic authentication scheme is supported.
As usually, this information is given by NTRIP service provider.
• NMEA - this box allows using appropriate parameter to receive/no receive the GGA
messages for NTRIP caster:
• -1 – receiver will not send NMEA GGA messages to NTRIP caster.
• 0 – receiver will send NMEA GGA message to NTRIP caster only once after connection
to the caster is established.
• [1...86400] – receiver will send NMEA GGA messages to the NTRIP caster
periodically, every specified number of seconds.
Mountpoint drop-down list box allows to select the necessary mount point from the list. This
drop-down list box specifies the mount point of the NTRIP caster to get data from. The detailed
information about each mount point it is possible to obtain and view clicking the Source Table
button.
The description of these parameters exceeds the scope of this document, see ModemVU Software
Manual, available from http:///www.javad.com for detailed information.

Settings for the SERVER subtab

The Server subtab allows user to setup parameters to establish connection with JAVAD server
(Figure 3-11).
• IP address - The value of this field should match the IP address of the Javad Server to use.
• Port - The value of this field should match the IP port the Javad Server is listening on for
connections.
www.javad.com
Configuring the Internal/External UHF Modem/GSM Module
Figure 3-11. SERVER subtab
Configuration
Configuring the GSM module for Internet access
55
